Chapter 6 : LCD FUNCTIONS DESCRIPTION
1 [INPUT] + ENTER.
1-1 [input status] + ENTER.
Indicates the status of the selected input.
1-2 [input type] + ENTER.
c Select an input with
+ ENTER.
d Select the input signal type with + ENTER between:
• [SDTV Composite] • [SDTV RGB SOG]
• [SDTV S.VIDEO] • [SDTV RGBS ana.]
• [SDTV YUV] • [Computer SOG]
• [SDTV RGBS TTL] • [Computer HV/C]
• [HDTV] = HDTV input format (720p, 1035i and 1080i).
• [Audio only] = select this function if you only want to connect an audio source (no video signal needed).
e Then for [SDTV Composite], and [SDTV S.VIDEO], select the video standard with + ENTER between:
• [NTSC / PAL / SECAM] = automatic NTSC, PAL, and SECAM standard detection.
• [NTSC] = NTSC standard detection only.
• [PAL] = PAL standard detection only.
• [NTSC 4.43 60 Hz] = NTSC 4.43 60Hz detection. • [PAL 4.43 60Hz] = PAL 4.43 60Hz detection.
• [SECAM] = SECAM standard detection only. • [B & W 50/60 Hz] = Black and White detection.
1-3 [used input] + ENTER.
Select an input and then select an item
+ ENTER between:
• [used] = A signal is connected to the input.
• [unused] = No signal is connected to the input. The input is unused.
• [freeze] = The input button is assign to the FREEZE function (available on the OFD802 & OFX802 only).
• [display logos] = The input button is assign to the display logos function (available on the OFX802 only).
1-4 [H sync load] + ENTER.
Select for each input the load of the H Sync. with
+ ENTER.
1-5 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2
[OUTPUT] + ENTER.
2-1 [output status] + ENTER.
Indicates the status of the output.
2-2 [output format] + ENTER.
Select one of the following output format with
+ ENTER.
• If [fast switching] = [internal rate], the LCD window displays the following formats :
• [VGA 60 Hz 4/3] = 640 x 480 at 60 Hz. • [VGA 75 Hz 4/3] = 640 x 480 at 75 Hz.
• [SVGA 60 Hz 4/3] = 800 x 600 at 60 Hz. • [SVGA 75 Hz 4/3] = 800 x 600 at 75 Hz.
• [XGA 60 Hz 4/3] = 1024 x 768 at 60 Hz. • [XGA 75 Hz 4/3] = 1024 x 768 at 75 Hz.
• [SXGA 60 Hz 4/3] = 1280 x 1024 at 60 Hz. • [SXGA 75 Hz 4/3] = 1280 x 1024 at 75 Hz.
• [SXGA+ 60 Hz 4/3] = 1400 x 1050 at 60 Hz.
• [D-ILA - 4/3] = 1365 x 1024 at 75 Hz.
• [D-ILA - 16/9] = 1365 x 768 at 75 Hz.
• [HDTV 480p] = 853 x 480 at 60 Hz.
• [HDTV 720p] = 1280 x 720 at 60 Hz.
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format corresponding
to the native resolution of the display device. Thus, the display device will not have to scale the image and
the result will be better.
