OCTO range Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 21
• If [fast switching] = [input # X], the LCD window displays the following formats:
• [640 x 480 L] = Line doubler: 480p/59.94 Hz or 576p/50 Hz.
• [800 x 600 L] = 800 x 600 at 50 Hz or 59.94 Hz.
• [1024 x 768 L] = 1024 x 768 at 50 Hz or 59.94 Hz.
• [1280 x 1024 L] = 1280 x 1024 at 50 Hz or 59.94 Hz.
• [1400 x 1050 L] = 1400 x 1050 at 50 Hz or 59.94 Hz.
• [1365 x 1024 L] = 1365 x 1024 at 50 Hz or 59.94 Hz.
• [1365 x 768 L] = 1365 x 768 at 50 Hz or 59.94 Hz - 16/9.
• [HDTV 480p] = 853 x 480 at 50 Hz or 59.94 Hz - 16/9.
• [HDTV 720p] = 1280 x 720 at 50 Hz or 59.94 Hz - 16/9.
NOTE: The output rate is 50 Hz for PAL & SECAM video inputs, or 59.94 Hz for NTSC video inputs.
2-3 [output sync] + ENTER.
Select the Output Sync. type with
+ ENTER.
• [H&V] = H & V Separate Sync.
• [COMP] = Composite Sync.
• [SOG] = Sync On green.
2-4 [type of screen] + ENTER.
Select an item with
+ ENTER.
• [4/3] = If your image is displayed on a 4/3 wall mounted projection screen shape.
• [16/9] = If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
2-5 [test pattern] + ENTER.
Select an item with
+ ENTER.
• [no pattern] = No test pattern is displayed.
• [centering] = Displays onto the output a centering pattern (for position and size adjustments).
NOTE: In seamless mode, you can adjust the centering pattern position with the following function:
[H position]: Adjust the Horizontal position with + ENTER.
[V position]: Adjust the Vertical position with + ENTER.
[H size]: Adjust the Horizontal size with + ENTER.
[V size]: Adjust the Vertical size with + ENTER.
• [color bar] = Displays onto the output a color bar pattern.
3 [SWITCHING] + ENTER.
3-1 [fast switching] + ENTER.
Select an item with
+ ENTER.
• [internal] = The output frame rate is 60 Hz or 75 Hz depending of the selected output format (LCD menu #
2-2). A higher frame frequency gives a better visual aspect when displaying static pictures.
• [input # x] = The output frame rate is identical to the "Input # x" Frame Rate : 50 Hz if the input video
standard is PAL or SECAM and 59.94 Hz if the input video standard is NTSC. This function
allows improving the motion pictures.
3-2 [seamless] + ENTER.
c Select the computer input take as reference with
+ ENTER.
• [computer #1] = The OCTO is in Seamless mode. The output format is the same as computer #1 format.
• [computer #8] = The OCTO is in Seamless mode. The output format is the same as computer #8 format.
d Then select the aspect ratio (4/3 or 16/9) of your display device.
