Chapter 4 : USING FRAME STORE AND LOGO INSERTION (continued) OCTO range
PAGE 16
4-2. FRAME STORE
This function allows memorizing a frame (an image) in order to display it at any time during the show.
IMPORTANT: • The output format used when displaying the frame should be the same that the output format used
during the FRAME storing.
• In SEAMLESS mode, the referenced input cannot be used to acquire or displays a frame.
• The FRAME is not available when the CLEAN CUT is activated.
• HOW TO STORE A FRAME:
c Select the source of the frame to be stored (with the INPUT SELECTION buttons).
d Select the record frame mode (LOGOS/FRAME > record frame): the device displays a white rectangle
corresponding to the frame selection area onto the output. If necessary adjust the position and size of the frame
selection area (IMAGE > pos settings).
e Store the frame (LOGOS/FRAME > record frame > store). The memorization starts and will take about 2
minutes.
NOTE: For motion picture, you can use the FREEZE function, before doing the memorization.
• HOW TO ASSIGN A FRAME:
f In the assignment menu (LOGOS/FRAME > use logo/frame > assignment), select the input that you want to
assign the FRAME, then select an INDEX (1 or 2) and select frame.
NOTE: To remove the FRAME from an input, select the corresponding input & index and select none.
• HOW TO DISPLAY ON or OFF the FRAME:
g To display ON the FRAME, select the input corresponding to the frame with the INPUT SELECTION buttons. The
FRAME appears onto the output, instead of the source connected to this input.
NOTE: If the FRAME doesn't appear: verify that the display function of the corresponding input is not set in the
OFF position (LOGOS/FRAME > use logo/frame > display). In this case, presses ENTER to set it in the
ON position.
h To display OFF the frame, set the display function in OFF position (LOGOS/FRAME > use logo/frame > display
> OFF).
TRICK: To quickly display ON or OFF the FRAME, assign the FRAME to an unused input, and set the display
function in the ON position. Also to display ON the FRAME, press the corresponding INPUT
SELECTION button and then select another input to display OFF.
