452
13 Tableaux et sommaires
13.2
Distr
ibu
tion
des
plo
ts
et c
â
bles
d
e
r
a
c
c
o
rdem
e
n
t
pou
r les
int
e
rf
ac
es
de
Prise femelle RJ45 pour Interface Ethernet
Longueur câble max.: non blindé: 100 m
blindé: 400 m
Plot
Signal
Description
1
TX+
Transmit Data
2
TX–
Transmit Data
3
REC+
Receive Data
4
libre
5
libre
6
REC–
Receive Data
7
libre
8
libre
