OCTO-QUATTRO™
PAGE 30
Chapter 10 : TECHNICAL SPECIFICATIONS
10-1. COMPUTER & VIDEO INPUTS
• COMPUTER (on HD15 female connector).
Line frequency: Up to 110 kHz.
Frame frequency: Up to 130 Hz.
Resolution: Up to 1600 x 1280.
Sync. types: RGBHV, RGB/S, RGsB (Sync On Green).
Levels: R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance: R, G, B = 75 ohms.
H = 75 ohms or Hi-Z.
V = Hi-Z.
• RGB/S VIDEO (on HD15 female connector).
Frequency: 15.625 kHz / 50 Hz (625 lines).
15.735 kHz / 60 Hz (525 lines).
Levels: R, G, B = 0.7 Vp/p.
SYNC. = 0.3 Vp/p or TTL.
Impedance: RGB = 75 ohms.
SYNC. = 75 ohms or Hi-Z.
• COMPONENT (on HD15 female connector).
Frequency: 15.625 kHz / 50 Hz (625 lines).
15.735 kHz / 60 Hz (525 lines).
Levels: Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
R-Y = 0.7 Vp/p.
B-Y = 0.7 Vp/p.
Impedance: Y, R-Y , B-Y = 75 ohms.
• HDTV (on HD15 female connector).
Formats: 720p, 1035i, 1080i.
Levels: Y = 1 Vp/p (0.7 V + sync.).
R-Y = 1 Vp/p (0.7 V + sync.).
B-Y = 1 Vp/p (0.7 V + sync.).
Sync.: Tri-level: ±0.3V (positive/negative).
Bi-level: 0.3V (negative).
Impedance: 75 ohms.
• S.VIDEO (on 4-pin mini DIN connector or 2 BNC connectors or HD15 female connector).
Standard: PAL / SECAM: 15.625 kHz / 50 Hz - 625 lines.
NTSC (3.58 MHz / 4.43 MHz): 15.735 kHz / 60 Hz - 525 lines.
Levels: Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
C = 0.3 Vp/p (Chroma Burst).
Impedance: 75 ohms.
• COMPOSITE VIDEO (on BNC connector or HD15 female connector).
Standard: PAL / SECAM: 15.625 kHz / 50 Hz - 625 lines.
NTSC (3.58 MHz / 4.43 MHz): 15.735 kHz / 60 Hz - 525 lines.
Level: 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Impedance: 75 ohms.
