OCTO-QUATTRO™ Chapter 5 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 15
2-3 [output sync] + ENTER.
Select the Output Sync. type with  + ENTER.
• [H&V] = H & V Separate Sync.
• [COMP] = Composite Sync.
• [SOG] = Sync On green.
2-4 [type of screen] + ENTER.
Select an item with  + ENTER.
• [4/3] = If your image is displayed on a 4/3 wall mounted projection screen shape.
• [16/9] = If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
2-5 [test pattern] + ENTER.
Select an item with  + ENTER.
• [no pattern] = No test pattern is displayed.
• [centering] = Displays onto the output a centering pattern (for position and size adjustments).
• [color bar] = Displays onto the output a color bar pattern.
3 [SWITCHING] + ENTER.
3-1 [fast switching] + ENTER.
Select an item with  + ENTER.
• [internal] = The output frame rate is 60 Hz or 75 Hz depending of the selected output format (LCD menu #
2-2). A higher frame frequency gives a better visual aspect when displaying static pictures.
• [input # x] = The output frame rate is identical to the "Input # x" Frame Rate : 50 Hz if the input video
standard is PAL or SECAM and 59.94 Hz if the input video standard is NTSC. This function
allows improving the motion pictures.
4
[IMAGE] + ENTER.
NOTE: The image menu contents will be different in case of computer or video on the input selected.
4-1 [centering] + ENTER.
Adjust automatically the image in the centering pattern.
4-2 [pos. settings] + ENTER.
Select one of the following function with  + ENTER.
4-2-1 [H position] + ENTER.
Adjust the Horizontal position with  + ENTER.
4-2-2 [V position] + ENTER.
Adjust the Vertical position with  + ENTER.
4-2-3 [H size] + ENTER.
Adjust the Horizontal size with  + ENTER.
4-2-4 [V size] + ENTER.
Adjust the Vertical size with  + ENTER.
4-3 [aspect ratio] + ENTER.
Select the Aspect Ratio of your input source with  + ENTER.
• [4/3 standard] = 4/3 input format.
• [16/9 letterbox] = Letterbox input format.
• [WS anamorphic] = Widescreen Anamorphic input format (video) or 16/9 input format (computer).
4-4 [H. smooth] + ENTER.
Adjust the horizontal smooth with  + ENTER.
