OCTO-QUATTRO™ Chapter 8 : REMOTE CONTROL PROGRAMMER'S GUIDE (continued)
PAGE 27
8-4. COMMANDS AND RESPONSES TABLE (continued)
VALUE ASCII
COMMAND
RESPONSE
COMMAND
DESCRIPTION
TYPE
MIN MAX DESCRIPTION
COMMUNICATION PORT COMMANDS
ne LANE Communication port selection Rd/Wr 0 1 0 = RS232 1 = LAN
nr LANR Reset of the LAN parameters. Rd/Wr 0 1 1 = reset.
ns LANS Store the LAN parameters. Rd/Wr 0 1 1 = store.
na ADIP
IP address and port selection (for
modification)
Rd/Wr 0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw IPA_
First byte of the address selected by the
na command.
Rd/Wr 0 255
nx IPB_
Second byte of the address selected by
the na command.
Rd/Wr 0 255
ny IPC_
Third byte of the address selected by the
na command.
Rd/Wr 0 255
nz IPD_
Forth byte of the address selected by the
na command.
Rd/Wr 0 255
np PORT
Number of the port (local or remote)
selected by the na command.
Rd/Wr 0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk NTMK Netmask. Rd/Wr 0 24
Value = number of bit to 0 (from right).
example: 2
 255.255.255.252
3  255.255.255.248
.............
8
 255.255.255.0
.............
24
 255.0.0.0
nt TCP Protocol selection. Rd/Wr 0 1 0 = UDP 1 = TCP
OTHERS COMMANDS
M STO Image parameters storing. Rd/Wr 0 1 1 = STORE action (automatic reset).
R REC RECALL: Recall the image parameters. Rd/Wr 0 1 1 = RECALL action (automatic reset).
? DEV Device type. Rd 0 65535 26 = OTR401.
# DEV...... Send all device parameters. Rd
NOTE: Rd/Wr = Read and write command. Rd = Read only command.
