Chapter 5 : LCD FUNCTIONS DESCRIPTION
1 [INPUT] + ENTER.
1-1 [input status] + ENTER.
Indicates the status of the selected input.
1-2 [input type] + ENTER.
c Select an input with  + ENTER.
d Select the input signal type with  + ENTER between:
• [SDTV Composite] • [SDTV RGB SOG]
• [SDTV S.VIDEO] • [SDTV RGBS ana.]
• [SDTV YUV] • [Computer SOG]
• [SDTV RGBS TTL] • [Computer HV/C]
• [HDTV] = HDTV input format (720p, 1035i and 1080i).
• [Audio only] = select this function if you only want to connect an audio source (no video signal needed).
e Then for [SDTV Composite], and [SDTV S.VIDEO], select the video standard with  + ENTER between:
• [NTSC / PAL / SECAM] = automatic NTSC, PAL, and SECAM standard detection.
• [NTSC] = NTSC standard detection only.
• [PAL] = PAL standard detection only.
• [NTSC 4.43 60 Hz] = NTSC 4.43 60Hz detection. • [PAL 4.43 60Hz] = PAL 4.43 60Hz detection.
• [SECAM] = SECAM standard detection only. • [B & W 50/60 Hz] = Black and White standard
detection.
1-3 [used input] + ENTER.
Select an input and then select an item  + ENTER between:
• [used] = A signal is connected to the input.
• [unused] = No signal is connected to the input. The input is unused.
1-4 [H sync load] + ENTER.
Select for each input the load of the H Sync. with  + ENTER.
1-5 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2
[OUTPUT] + ENTER.
2-1 [output status] + ENTER.
Indicates the status of the output.
2-2 [output format] + ENTER.
Select one of the following output format with  + ENTER.
• If [fast switching] = [internal rate], the LCD window displays the following formats :
• [VGA 60 Hz 4/3] = 640 x 480 at 60 Hz. • [VGA 75 Hz 4/3] = 640 x 480 at 75 Hz.
• [SVGA 60 Hz 4/3] = 800 x 600 at 60 Hz. • [SVGA 75 Hz 4/3] = 800 x 600 at 75 Hz.
• [XGA 60 Hz 4/3] = 1024 x 768 at 60 Hz. • [XGA 75 Hz 4/3] = 1024 x 768 at 75 Hz.
• [SXGA 60 Hz 4/3] = 1280 x 1024 at 60 Hz. • [SXGA 75 Hz 4/3] = 1280 x 1024 at 75 Hz.
• [SXGA+ 60 Hz 4/3] = 1400 x 1050 at 60 Hz.
• [D-ILA - 4/3] = 1365 x 1024 at 75 Hz.
• [D-ILA - 16/9] = 1365 x 768 at 75 Hz.
• [HDTV 480p] = 853 x 480 at 60 Hz.
• [HDTV 720p] = 1280 x 720 at 60 Hz.
• If [fast switching] = [input # X], the LCD window displays the following formats:
• [640 x 480 L] = Line doubler: 480p/59.94 Hz or 576p/50 Hz.
• [800 x 600 L] = 800 x 600 at 50 Hz or 59.94 Hz.
• [1024 x 768 L] = 1024 x 768 at 50 Hz or 59.94 Hz.
• [1280 x 1024 L] = 1280 x 1024 at 50 Hz or 59.94 Hz.
• [1400 x 1050 L] = 1400 x 1050 at 50 Hz or 59.94 Hz.
• [1365 x 1024 L] = 1365 x 1024 at 50 Hz or 59.94 Hz.
• [1365 x 768 L] = 1365 x 768 at 50 Hz or 59.94 Hz - 16/9.
• [HDTV 480p] = 853 x 480 at 50 Hz or 59.94 Hz - 16/9.
• [HDTV 720p] = 1280 x 720 at 50 Hz or 59.94 Hz - 16/9.
NOTE: The output rate is 50 Hz for PAL & SECAM video inputs, or 59.94 Hz for NTSC video inputs.
