OCTO-QUATTRO™ Chapter 5 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 17
6 [CONTROL] + ENTER.
6-1 [versions] + ENTER.
Version _._= update version. I = Identification number. K, S, F, O, V = status of the internal firmware versions.
6-2 [key locking] + ENTER.
Select an item with  and change the mode with ENTER.
• [menus] = Locks/unlocks the LCD CONTROL switches.
• [input] = Locks/unlocks the INPUT SELECTION and FREEZE switches.
• [all] = Locks/unlocks all the front panel switches.
NOTE: To unlock presses simultaneously on ENTER and EXIT.
• [autolock] = Allows to select an input only if a signal is connected.
6-3 [transition] + ENTER.
Select an item with  + ENTER
6-3-1
[fade color] + ENTER.
This function allows selecting the color of the fade during the transition. Select a color (red, green and bleu)
with  + ENTER and adjust the level with  + ENTER. During the adjustment the color is
displayed onto the output. To obtain the black color, set the 3 levels to the minimum. To obtain the white
color, set the 3 levels to maximum. To obtain the grey color, set the 3 levels in the middle.
6-3-2 [clean cut] + ENTER.
This function allows a clean switching thanks to a fast freeze of the displayed source. Select a function with

+ ENTER.
• [from computer] = The CLEAN CUT operates only when switching from a computer source. The others
switching operates with a fade color.
• [from video] = The CLEAN CUT operates only when switching from a computer source. The others
switching operates with a fade color.
• [from all] = The CLEAN CUT operates when switching from all sources.
6-4 [display ON/OFF] + ENTER.
6-4-1
[baud rate] + ENTER.
Select the baud rate of the display device with  + ENTER between 9600, 2400 & 1200.
6-4-2 [message ON] + ENTER.
This function allows to store the ON message of your display device. Then your OCTO-QUATTRO
™
coming out the STANDBY mode, this one send the stored message to your display device. The ON message
can be composed up to 50 bytes. For each byte, select the needed ASCII code with and validate with
ENTER.
NOTE: The 0 value allows to displays: no data.
6-4-3 [message OFF] + ENTER.
This function allows to store the OFF message of your display device. Then your OCTO-QUATTRO
™
going into the STANDBY mode, this one send the stored message to your display device. The OFF message
can be composed up to 50 bytes. For each byte, select the needed ASCII code with , then press ENTER.
NOTE: The 0 value allows to displays: no data.
6-4-4 [reset messages] + ENTER.
Allows to reset the ON & OFF messages.
6-4-5 [timer: off] + ENTER.
When the device any more detect a signal on the selected input, this one is set in the STANDBY mode after
the duration of your choice. Select a duration with  + ENTER.
NOTE: Select OFF to inactive this function.
6-4-6 [switch off] + ENTER.
Allows to set the device in STANDBY mode. To coming out the STANDBY mode , press one of the front
panel buttons.
6-5 [2:2 pull down] + ENTER.
Select an item and validate with ENTER.
• [auto] = Automatic recognition and correction of the 2:2 pull down.
• [off] = Disable the 2:2 pull down correction.
