6 Programmation: Programmer les contours
6.6 Cont
our
nag
e
s – Pr
ogr
ammation flexible de cont
ours FK
(option
d
e
logiciel)
Exemple: Programmation FK 2
0 BEGIN PGM FK2 MM
1 BLK FORM 0.1 Z X+0 Y+0 Z-20
Définition de la pièce brute
2 BLK FORM 0.2 X+100 Y+100 Z+0
3 TOOL CALL 1 Z S4000
Appel de l'outil
4 L Z+250 R0 FMAX
Dégager l'outil
5 L X+30 Y+30 R0 FMAX
Prépositionner l’outil
6 L Z+5 R0 FMAX M3
Prépositionner l’axe d’outil
7 L Z-5 R0 F100
Aller à la profondeur d’usinage
X
Y
30
30
R30
R20
60°
55
10
10
