EDGE Pro Ti CNC Manuel d’instructions 807662 Révision 2
159
Schémas de câblage
Circuit imprimé MCC
Circuit imprimé MCC
SHEET
SHEET
J2 DRIVE/ENCODER
J3 I/O 25-48 (NOT USED)
J1 I/O 1-24
9-D3
8-D1
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
35
36
37
38
39
40
J2
J3
25 AXIS 6Z CH
26 LOGIC GND
27 LOGIC GND
28 ANALOG COM
29 AXIS 1 ANALOG
30 AXIS 2 ANALOG
31 AXIS 3 ANALOG
32 AXIS 4 ANALOG
33 AXIS 5 ANALOG
34 AXIS 6 ANALOG
24 AXIS 6B CH
23 AXIS 6A CH
22 AXIS 5Z CH
21 AXIS 5B CH
20 AXIS 5A CH
19 AXIS 4Z CH
18 AXIS 4B CH
17 AXIS 4A CH
16 AXIS 3Z CH
15 AXIS 3B CH
1 AXIS 1 ENABLE
2 AXIS 2 ENABLE
3 AXIS 3 ENABLE
4 AXIS 4 ENABLE
14 AXIS 3A CH
13 AXIS 2Z CH
12 AXIS 2B CH
11 AXIS 2A CH
10 AXIS 1Z CH
9 AXIS 1B CH
8 AXIS 1A CH
7 /WDOG ENABLE
5 AXIS 5 ENABLE
6 AXIS 6 ENABLE
35 LOGIC GND
36 +5V LOGIC
40 LOGIC GND
39 -12V LOGIC
38 +12V LOGIC
37 +5V LOGIC
223014 (6 AXIS DRV/ENC)
223016 (I/O 1-24) BLACK
50 GROUND
49 GROUND
48 OUTPUT 24
47 INPUT 24
37 INPUT 19
38 OUTPUT 19
39 INPUT 20
40 OUTPUT 20
41 INPUT 21
42 OUTPUT 21
43 INPUT 22
44 OUTPUT 22
45 INPUT 23
46 OUTPUT 23
36 OUTPUT 18
35 INPUT 18
6 OUTPUT 3
5 INPUT 3
7 INPUT 4
8 OUTPUT 4
9 INPUT 5
10 OUTPUT 5
11 INPUT 6
12 OUTPUT 6
13 INPUT 7
14 OUTPUT 7
4 OUTPUT 2
3 INPUT 2
2 OUTPUT 1
1 INPUT 1
15 INPUT 8
16 OUTPUT 8
17 INPUT 9
18 OUTPUT 9
19 INPUT 10
20 OUTPUT 10
21 INPUT 11
22 OUTPUT 11
23 INPUT 12
24 OUTPUT 12
34 OUTPUT 17
33 INPUT 17
32 OUTPUT 16
31 INPUT 16
30 OUTPUT 15
29 INPUT 15
28 OUTPUT 14
27 INPUT 14
26 OUTPUT 13
25 INPUT 13
PCB5
6 AXIS MCC PCB
141191
J1
(NOT USED)
Z
AC
