SMART FADE™ Chapter 2 : INSTALLATION
PAGE 6
Chapter 2 : INSTALLATION
IMPORTANT: Please read all the safety instructions (page 2 to 4) before starting.
• Table Top Mounting: The SMART FADE ™ can be used directly on a table: the unit is equipped with 4 plastic feet.
• Rack Mounting: The SMART FADE ™ is compatible with a 19" enclosure . Please follow the instructions below to
install the SMART FADE ™ into a 19” rack :
c Screw the supplied 19” brackets to the sides of the SMART FADE™ .
d Attach the SMART FADE ™ to the rack by using 4 screws in the front panel holes (screws
are not included).
IMPORTANT: • The openings in the top cover and in the rear panel are for cooling. Do not cover these
openings.
• Be sure that no weight is added to the SMART FADE ™ in excess of 2 kg (4.4 lbs.).
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and local
electrical codes.
