Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART FADE™
PAGE 32
10-4. COMMANDS AND RESPONSES TABLE
The following table resumes commands which are recognized as valid and the responses that will be returned to the control
device (on RS-232 port).
VALUE EXAMPLE COMMAND
ASCII
RESPONSE
COMMAND
DESCRIPTION MIN MAX COMMAND RESPONSE ACTION EXPLANATION
INPUT COMMANDS
i IPRES INPUT PRE-SELECTION. 0 25 1i IPRES1 PRE-SELECTS COMPUTER 1.
r IRGB
VIDEO TYPE OF RGB/YUV
INPUT.
0 3 r IRGB1
READS VIDEO TYPE RGB/YUV
INPUT.
w ISTDC1 INPUT STANDARD C.VIDEO 1. 0 4 w ISTDC10
READS THE VIDEO STANDARD
DETECTION.
x ISTDC2 INPUT STANDARD C.VIDEO 2. 0 4 x ISTDC21
READS THE VIDEO STANDARD
DETECTION.
y ISTDS1 INPUT STANDARD S.VIDEO 1. 0 4 y ISTDS14
READS THE VIDEO STANDARD
DETECTION.
z ISTDS2 INPUT STANDARD S.VIDEO 2. 0 4 z ISTDS21
READS THE VIDEO STANDARD
DETECTION.
m VMODE
C. VIDEO & S.VIDEO MODE
SELECTION.
0 3 1m VMODE1 SELECTS MODE B.
q PCHAN
SELECTS THE INPUT TO MODIFY
WITH g AND h COMMANDS.
8 22 q PCHAN8 SELECTS C.VIDEO 1.
g IRGBX
VIDEO TYPE OF RGB/YUV
INPUTS.
0 3 g IRGBX1
READS VIDEO TYPE OF THE
RGB/YUV INPUTS.
h ISTDX INPUT STANDARD. 0 4 1h ISTDX1 SELECTS NTSC STANDARD.
OUTPUT COMMANDS
u SSYNC REFERENCE SYNC. 0 25 u SSYNC1 READS THE REFERENCE SYNC.
O OFMT OUTPUT FORMAT. 0 13 O OFMT2 READS THE OUTPUT FORMAT.
o OSIG OUTPUT SYNC TYPE. 0 1 1o OSIG1
SETS THE OUTPUT SYNC TO COMP.
SYNC.
IMAGE COMMANDS (VIDEO ONLY)
H HPOS HORIZONTAL POSITION. 0 255 20H HPOS20 SETS H. POSITION TO 20.
V VPOS VERTICAL POSITION. 0 255 V VPOS73 READS V POSITION.
W HSIZ HORIZONTAL SIZE. 0 255 W HSIZ128 READS H WIDTH.
S VSIZ VERTICAL SIZE. 0 255 157S VSIZ157 SETS V SIZE TO 157.
B BRGT BRIGHTNESS ADJUSTMENT. 0 255 B BRGT15 READS BRIGHTNESS LEVEL.
C CONTR CONTRAST ADJUSTMENT. 0 255 C CONTR50 READS CONTRAST LEVEL.
s COLOR COLOR SATURATION. 0 255 s COLOR125
READS COLOR SATURATION
LEVEL.
T HUE HUE ADJUSTMENT (NTSC ONLY) 0 255 T HUE120 READS HUE LEVEL.
f SHARP IMAGE PROCESS. 0 7 f SHARP4 READS IMAGE PROCESS.
b IASP ASPECT RATIO. 0 2 2b IASP2 SETS ASPECT RATIO TO16/9.
EFFECTS COMMANDS
| CFG
CONFIGURATION OF THE
EFFECT.
0 255 2| CFG2
SETS THE EFFECT TO HOLDING
TITLE.
@ AP
MANUAL FADE PERCENTAGE
BETWEEN COMPUTER INPUT &
VIDEO INPUT.
0 100 50@ AP50
SETS THE MANUAL FADE TO SEND
OUT 50% OF THE TWO INPUTS.
~ FTIM AUTO. FADING TIME. 0 255 20~ FTIM20 SETS AUTO. FADE TO 2 SEC.
AUDIO COMMANDS
M AMAST AUDIO MASTER VOLUME. 0 255 10M AMAST 10
SETS AUDIO MASTER VOLUME TO
10.
a ALEV AUDIO LEVEL 0 255 a ALEV50
READS AUDIO LEVEL OF
SELECTED CHANNEL.
A ACHAN
AUDIO CHANNEL (FOLLOW OR
BREAKAWAY MODE)
0 25 3A ACHAN3
SETS C.VIDEO 1 FOR AUDIO
CHANNEL.
