Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART FADE™
PAGE 34
10-5. COMMANDS DESCRIPTION (continued)
c INPUT COMMANDS
• i command is used to pre-select an input.
- SMART FADE ™ ALONE APPLICATION
DECIMAL VALUE INPUT # SELECTION RESPONSE APPLICATION
0 BLACK IPRES0
1 COMPUTER 1 IPRES1
2 COMPUTER 2 IPRES2
3 C.VIDEO 1 IPRES3 SMF251
4 C.VIDEO 2 IPRES4 ALONE
5 S.VIDEO 1 IPRES5
6 S.VIDEO 2 IPRES6
7 RGB / YUV IPRES7
- SMART FADE ™ + SMART SWITCH VIDEO ™ APPLICATION
DECIMAL VALUE INPUT # SELECTION RESPONSE APPLICATION
0 BLACK IPRES0
2 EXTEND PC 2 IPRES2
4 EXTEND C.VIDEO 2 IPRES4
6 EXTEND S.VIDEO 2 IPRES6
8 C.VIDEO 1 IPRES8
9 C.VIDEO 2 IPRES9
10 C.VIDEO 3 IPRES10
11 C.VIDEO 4 IPRES11
12 C.VIDEO 5 IPRES12
13 C.VIDEO 6 IPRES13 SMF251
14 S.VIDEO 1 IPRES14 +
15 S.VIDEO 2 IPRES15 SMV415
16 S.VIDEO 3 IPRES16
17 S.VIDEO 4 IPRES17
18 S.VIDEO 5 IPRES18
19 S.VIDEO 6 IPRES19
20 RGB / YUV 1 IPRES20
21 RGB / YUV 2 IPRES21
22 RGB / YUV 3 IPRES22
23 COMPUTER 1 IPRES23
24 COMPUTER 2 IPRES24
25 COMPUTER 3 IPRES25
• r command is used to select the video type of the RGB/YUV input.
- SMART FADE ™ ALONE APPLICATION
DECIMAL VALUE SELECTION RESPONSE APPLICATION
0 YUV IRGB0
1 RGB/S (TTL) IRGB1 SMF251
2 RGsB (SOG) IRGB2 ALONE
3 RGB/S (75 Ω) IRGB3
• w, x, y, z commands are used to select the video standard of the C.VIDEO1, C.VIDEO2, S.VIDEO1and S.VIDEO2
input.
- SMART FADE ™ WITH OR WITHOUT SMART SWITCH VIDEO ™ APPLICATION
DECIMAL VALUE SELECTION RESPONSE APPLICATION
0 AUTOMATIC ISTD--0
1 NTSC (3.58 / 60Hz)) ISTD--1
2 PAL (4.43 / 50Hz) ISTD--2 ALL
3 SECAM ISTD--3
4 BLACK & WHITE ISTD--4
