SMART FADE™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE
PAGE 35
10-5. COMMANDS DESCRIPTION (continued)
• m command is used to select the C.VIDEO & S.VIDEO mode (front panel of the SMA415 & SMV415).
- SMART FADE
™
+ SMART SWITCH VIDEO
™
APPLICATION
DECIMAL
VALUE
SELECTION
RESPONSE
APPLICATION
0
MODE A (6 C.VIDEO + 3 S.VIDEO)
VMODE0
1
MODE B (4 C.VIDEO + 4 S.VIDEO)
VMODE1
SMF251
2
MODE C (2 C.VIDEO + 5 S.VIDEO)
VMODE2
+ SMV415
3
MODE AB (6 S.VIDEO)
VMODE3
• q command is used to select the input you want to modify with the g and h commands.
- SMART FADE
™
+ SMART SWITCH VIDEO
™
APPLICATION
DECIMAL
VALUE
INPUT # SELECTION
RESPONSE
APPLICATION
8
C.VIDEO 1
PCHAN8
9
C.VIDEO 2
PCHAN9
10
C.VIDEO 3
PCHAN10
11
C.VIDEO 4
PCHAN11
12
C.VIDEO 5
PCHAN12
13
C.VIDEO 6
PCHAN13
SMF251
14
S.VIDEO 1
PCHAN14
+
15
S.VIDEO 2
PCHAN15
SMV415
16
S.VIDEO 3
PCHAN16
17
S.VIDEO 4
PCHAN17
18
S.VIDEO 5
PCHAN18
19
S.VIDEO 6
PCHAN19
20
RGB / YUV 1
PCHAN20
21
RGB / YUV 2
PCHAN21
22
RGB / YUV 3
PCHAN22
• g command is used to select the video type of the RGB / YUV inputs.
- SMART FADE
™
+ SMART SWITCH VIDEO
™
APPLICATION
DECIMAL
VALUE
SELECTION
RESPONSE
APPLICATION
0
YUV
IRGBX0
1
RGB/S (TTL)
IRGBX1
SMF251
2
RGsB (SOG)
IRGBX2
+ SMV415
3
RGB (75
Ω)
IRGBX3
NOTE: The g command acts on the input selected with the q command.
• h command is used to select the video standard of the video inputs.
- SMART FADE
™
+ SMART SWITCH VIDEO
™
APPLICATION
DECIMAL
VALUE
SELECTION
RESPONSE
APPLICATION
0
AUTOMATIC
ISTDX0
1
NTSC (3.58 / 60Hz)
ISTDX1
SMF251
2
PAL (4.43 / 50Hz)
ISTDX2
+
3
SECAM
ISTDX3
SMV415
4
BLACK & WHITE
ISTDX4
NOTE: The h command acts on the input selected with the q command.
