Chapter 9 : CONTROL SOFTWARE SMART FADE™
PAGE 26
Chapter 9 : CONTROL SOFTWARE
9-1. CONNECTION
• CONNECTING THE RS-232:
• If you use the SMART FADE
™
alone :
- Connect the serial port of your Control Device (PC) to the REMOTE CONTROL (RS-232) connector (DB 9
Female) of the SMART FADE
™
with a straight cable (DB 9 Female / DB 9 Male).
• If you use the SMART FADE
™
with the SMART SWITCH VIDEO
™
:
- Connect the serial port of your Control Device (PC) to the REMOTE IN (PC) connector (DB 9 Female) of the
SMV415 with a straight cable (DB 9 Female / DB 9 Male).
- Connect the REMOTE OUT (CHAIN) connector (DB 9 M) of the SMV415 to the REMOTE CONTROL (RS
232) connector (DB 9 Female) of the SMART FADE
™
with a straight cable (DB 9 Female / DB 9 Male).
NOTE : The Remote Keypad (RK251) is not compatible when the SMART FADE
™
is used with the SMV415.
• If you use the SMART FADE
™
with the SMART SWITCH VIDEO
™
and with the SMART SWITCH AUDIO
™
:
- Connect the serial port of your Control Device (PC) to the REMOTE IN (PC) connector (DB 9 Female) of the
SMA415 with a straight cable (DB 9 Female / DB 9 Male).
- Connect the REMOTE OUT (CHAIN) connector (DB 9 Male) of the SMA415 to the REMOTE IN (PC)
connector (DB 9 Female) of the SMV415 with a straight cable (DB 9 Female / DB 9 Male).
- Connect the REMOTE OUT (CHAIN) connector (DB 9 M) of the SMV415 to the REMOTE CONTROL (RS-
232) connector (DB 9 Female) of the SMART FADE
™
with a straight cable (DB 9 Female / DB 9 Male).
NOTE: The Remote Keypad (RK251) is not compatible when the SMART FADE
™
is used with the SMV415 &
SMA415.
PC
SMF-251
PC
SMV
SMF251
PC
SMV
SMF251
SMA
KEYPAD
RK251
OR
