SMART FADE™ Chapter 7 : LCD FUNCTIONS DESCRIPTION
PAGE 19
Chapter 7 : LCD FUNCTIONS DESCRIPTION
1 [INPUT MENU] + ENTER.
1-1 [video standard] + ENTER.
Select an item with LCD CONTROL + ENTER.
• [auto] = Automatic recognition of the video standard for each input. If the standard is not detected correctly,
please use the [manual] setting.
• [manual] = Manual selection of the video standard for each input.
c Select an input with LCD CONTROL + ENTER.
• [c.video 1]
• [c.video 2]
• [s.video 1]
• [s.video 2]
d Select the video standard with LCD CONTROL + ENTER.
• [auto] = Automatic detection.
• [NTSC] = NTSC detection only.
• [PAL] = PAL detection only.
• [SECAM] = SECAM detection only.
• [Black & White] = Black and White detection only.
NOTE: If a SMART SWITCH VIDEO ™ is connected to the SMART FADE ™ , the LCD window displays all of
the C.VIDEO & S.VIDEO inputs. The inputs preceded by EXTEND (Example : EXTEND CV2) are
the inputs directly connected to the SMART FADE
™ .
1-2 [video status] + ENTER.
Indicates the status of the selected video input.
• [S.VIDEO 1] = Selected input.
• [NTSC] = Video standard of this input.
1-3 [RGB/YUV in] + ENTER.
Select the video signal connected to the RGB / YUV (R-Y / Y / B-Y) input :
• [YUV] = Component (YUV) video signal.
• [RGB/S (TTL)] = RGB/S video signal with TTL Composite Sync.
• [RGsB (SOG)] = RGsB video signal with analog Composite Sync. On Green.
• [RGB/S (75 Ω)] = RGB/S with an analog Composite Sync. (0.3 Vp/p).
NOTE: If a SMART SWITCH VIDEO ™ is connected to the SMART FADE ™ , first select an RGB/YUV input
(for example RGB/YUV1) and then select the video signal for this input. Renew this operation for all of
the other RGB/YUV inputs.
1-4 [comput status] + ENTER.
Indicates the status of the computer.
• [COMP] = Composite Sync. or [H&V] = H & V Separate Sync.
• [SXGA] = Name of the input format.
• [64.0K / 60Hz] = Input line frequency / Input frame frequency (kHz / Hz).
