SMART FADE™ Chapter 1 : INTRODUCTION
PAGE 5
ENGLISH
SMART FADE
™
Chapter 1 : INTRODUCTION
1-1. SUPPLIED EQUIPMENT
• 1 SMART FADE™ (SMF251).
• 1 Set of 19” Brackets.
• 1 AC Power supply cord.
• 1 VGA cable (HD15 Male / Male).
• 1 S.VIDEO (Y/C) cable.
• 1 BNC (x5) to HD 15 Female cable.
• 1 Set of 6 MCO (5-pins) female connectors (for audio connection).
• 1 Control Software (3.5" Disk).
• 1 User’s Manual.
1-2. GENERAL INFORMATION
The SMART FADE ™ , is a Video & Computer Mixer/Switcher with audio which integrates 3 functions for more
convenient and enhanced A/V presentations.
• It is a 5 VIDEO (2 x Composite, 2 x S.Video, 1 x Component or RGB/S) and 2 COMPUTER (up to 1280 x 1024)
inputs SEAMLESS MIXER/SWITCHER with a built-in SCALER.
Each VIDEO source is scaled and genlocked to match the resolution of your COMPUTER from 640 x 480 up to 1280 x
1024 (D-ILA in option).
• The SMART FADE ™ offers a Fade or a smooth or fast switching between :
- any VIDEO and 1 COMPUTER source (in seamless mode : Fade / Cut / Title),
- VIDEO sources (with a smooth or fast Cut to Black),
- COMPUTER sources (with a smooth or fast Cut to Black).
All video inputs are scaled to the selected computer input. This allows a "One-Time" adjustment for your display
resolution.
• The SMART FADE ™ is also a state of the art improved SCALER / LINE MULTIPLIER which significantly
increases the TV image’s resolution and brightness. The High Quality decoder includes an Advanced Comb Filter, an
emphasized "natural" color processing, a highly robust sync. detection and a new enhanced auto-adaptive de-interlacing
scheme (for motion artifacts) with correction of the «film to video» transfer (3/2 pulldown for the NTSC). It provides
you with a "film like" image.
• Each of the 7 inputs is fitted with an AUDIO STEREO line. It allows the audio to follow your video image or to
break away from your video. The level of any audio line is separately adjustable and a Master Control Volume is
dedicated to trim the overall sound level.
1-3. SMART FADE ™ REFERENCES
REFERENCES DESIGNATIONS
SMF251 SMART FADE ™ without option
SMF251-DILA SMART FADE ™ with optional D-ILA output format.
OPT-ROOM-1 Optional ROOM control output for SMART FADE ™ .
1-4. SMART FADE ™ OPTIONAL ACCESSORIES REFERENCES
REFERENCES DESIGNATIONS
RK251 Remote KEYPAD for SMART FADE ™ .
SMV415 SMART SWITCH VIDEO ™ : allows to extend up to 18 the video inputs of your SMF251.
SMA415 SMART SWITCH AUDIO ™ : allows to extend up to 18 the audio inputs of your SMF251.
SMB413 SMART BOOSTER ™ (multiway universal booster).
