Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART FADE™
PAGE 36
10-5. COMMANDS DESCRIPTION (continued)
d OUTPUT COMMANDS
• u command is used to select the reference sync.
- SMART FADE ™ ALONE APPLICATION.
DECIMAL
VALUE
SELECTION RESPONSE APPLICATION
0 INTERNAL RATE SSYNC0
1 COMPUTER 1 SSYNC1 SMF251
2 COMPUTER 2 SSYNC2 ALONE
3 VIDEO IN RATE SSYNC3
- SMART FADE ™ + SMART SWITCH VIDEO ™ APPLICATION.
DECIMAL
VALUE
SELECTION RESPONSE APPLICATION
0 INTERNAL RATE SSYNC0
2 EXTEND PC 2 SSYNC2
3 VIDEO IN RATE SSYNC3 SMF251
23 COMPUTER 1 SSYNC23 +
24 COMPUTER 2 SSYNC24 SMV415
25 COMPUTER 3 SSYNC25
• O command is used to select the output format.
- SMART FADE ™ WITH OR WITHOUT SMART SWITCH VIDEO ™ APPLICATION.
DECIMAL
VALUE
SELECTION (OUTPUT FORMAT) RESPONSE APPLICATION
0 VGA (640 x 480) at 60Hz OFMT0
1 PLASMA 42” (852 x 480) at 60Hz OFMT1
2 SVGA (800 x 600) at 60Hz OFMT2
3 MAC (640 x 480) at 66Hz OFMT3
4 XGA (1024 x 768) at 60Hz OFMT4
5 PLASMA 50” (1280 x 768) at 56Hz OFMT5
6 SXGA (1280 x 1024) at 60Hz OFMT6
7 VGA (640 x 480) at 75Hz OFMT7
8 PLASMA 42” (852 x 480) at 72Hz OFMT8
ALL APPLICATIONS
WITH NO COMPUTER
USED AS REFERENCE
SYNC.
9 SVGA (800 x 600) at 75Hz OFMT9
10 MAC 16” (832 x 624) at 75Hz OFMT10
11 XGA (1024 x 768) at 75Hz OFMT11
12 PLASMA 50” (1280 x 768) at 75Hz OFMT12
13 SXGA (1280 x 1024) at 75Hz OFMT13
14 D-ILA (1365 x 1024) at 75Hz OFMT14
NOTE: The O command is active only if "no computer" is selected as a reference (the response of the n command
should be 0 or 3).
•
o command is used to select the output sync type.
DECIMAL
VALUE
SELECTION
(OUTPUT SYNC TYPE)
RESPONSE APPLICATION
0 H & V SEPARATE SYNC. OSIG0 ALL
1 COMPOSITE SYNC. OSIG1
