Chapter 7 : LCD FUNCTIONS DESCRIPTION SMART FADE™
PAGE 22
4 [EFFECT MENU] + ENTER.
4-1 [fading effect] + ENTER.
Select a Fading Effect with LCD CONTROL + ENTER.
• Fading 0.5 Sec.
• Fading 1 Sec.
• Fading 2 Sec.
• Fading 3 Sec.
• Fading 4 Sec.
• Fading 5 Sec.
4-2 [title effect] + ENTER.
Select a Title effect with LCD CONTROL + ENTER.
• Title 5 Sec: Insert the pre-selected input (for 5 Sec.) onto the displayed output.
• Holding Title: Insert the pre-selected input (with TAKE) onto the displayed Output. Press TAKE again to
release the Holding Title Effect.
4-3 [video switch] + ENTER.
This function is active only for "non seamless" transition.
4-3-1 [smooth cut] + ENTER.
• [Yes] = Smooth Cut to Black between the pre-selected input and the displayed output.
• [No] = Fast Cut to Black between the pre-selected input and the displayed output.
4-3-2 [black delay] + ENTER.
Select the duration of the Black Delay. This Black Delay allows to avoid any unwanted visual effects (drop
out or glitch) on your display device.
• [short] = 1 second delay.
• [long] = 3 second delay.
5 [AUDIO MENU] + ENTER.
5-1 [master volume] + ENTER.
Adjust the audio output level with LCD CONTROL + ENTER.
5-2 [audio level] + ENTER.
This function allows to separately adjust the level of each audio inputs. Select an audio input with LCD CONTROL
+ ENTER and adjust the level with LCD CONTROL + ENTER.
NOTE: The audio input must be selected in output before any level adjustments are done.
5-3 [audio source] + ENTER.
Select an item with LCD CONTROL + ENTER:
• [AUTO FOLLOW] = The audio follows the displayed video / computer output.
• [ xxxx ] = One of the audio input is permanently diffused.
NOTE: If a SMART SWITCH AUDIO ™ is connected to the SMART FADE ™ , the LCD window displays all of the
audio inputs. The inputs preceded by EXTEND (Example : EXTEND CV 2) are the inputs directly
connected to the SMART FADE
™ .
