SMART FADE™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE
PAGE 33
10-4. COMMANDS AND RESPONSES TABLE (continued)
VALUE EXAMPLE COMMAND
ASCII
RESPONSE
COMMAND
DESCRIPTION MIN MAX COMMAND RESPONSE ACTION EXPLANATION
STATUTS COMMANDS (READ ONLY)
U UNIT MEASURES UNITY IN kHz. 0 65535 U UNIT---- READ UNITY OF MEASURE.
l CLD
DURATION OF A COMPUTER
LINE.
0 65535 l CLD----
READ LINE FREQUENCY OF
SELECTED COMPUTER.
t CFD
NUMBER OF LINE PER FIELD OF
COMPUTER.
0 65535 t CFD----
READ LINE PER FIELD OF
SELECTED COMPUTER.
P CSTA COMPUTER STATUS. 0 31 P CSTA---- READ COMPUTER STATUS.
c CCHAN
INPUT NUMBER OF THE
COMPUTER WHICH STATUS IS
GIVEN.
0 25 c CCHAN1
COMPUTER STATUS IS FOR
COMPUTER 1 INPUT.
p VSTA VIDEO STATUS. 0 16 p VSTA13 READ THE VIDEO STATUS.
v VCHAN
INPUT NUMBER OF THE VIDEO
WHICH STATUS IS GIVEN.
0 22 v VCHAN7
VIDEO STATUS IS FOR RGB/YUV
INPUT.
n SCSTA REFERENCE SYNC STATUS. 0 25 n SCSTA1
REFERENCE SYNC IS COMPUTER
1.
I ICHAN SELECTED INPUT (DISPLAYED) 0 25 I ICHAN1
SELECTED INPUT IS COMPUTER
1 INPUT.
MISCELLANEOUS COMMANDS
Y CMD MISCELLANEOUS CONTROL. 0 4095 1Y CMD1 CUT ACTION.
? DEV DEVICE TYPE. 0 65535 ? DEV9
READ DEVICE TYPE (9 = SMART
FADE™).
K K_ "K" FIRMWARE VERSION. 0 65535 K K_ READ K VERSION.
L L_ "L" FIRMWARE VERSION. 0 65535 L L_ READ L VERSION.
R R_ "R" FIRMWARE VERSION. 0 65535 R R_ READ R VERSION.
X V_ "X" FIRMWARE VERSION. 0 65535 X V_ READ X VERSION.
10-5. COMMANDS DESCRIPTION
Values sent or received are in decimal.
Depending on the command letter, the value can be used as a linear control (ex : 255W to set the horizontal size to the
maximum) or as a set of bits (ex : P command with multiple controls).
In this case, the value must be converted in binary base to understand every bit action.
EXAMPLE: Host receives message CSTA25 (P command)
Decimal value 25 = Binary value 11001
25 = (32 x 0) + (16 x 1) + (8 x 1) + (4 x 0) + (2 x 0) + (1 x 1)
bit 0 = 1 means sync. detected.
bit 1 = 0 means H & V sync. detected.
bit 2 = 0 means non interlaced format detected.
bit 3 = 1 means computer selected = "referenced" computer.
bit 4 = 1 means the "Ref computer" format is in the range of compatibility.
bit 5 = 0 means the FADE and TITLE effects are not active.
