SMART FADE™ Chapter 7 : LCD FUNCTIONS DESCRIPTION
PAGE 21
3
[IMAGE MENU] + ENTER.
NOTE: This menu is active only on the displayed video source. This menu is not available for the COMPUTER
inputs. The image settings and adjustments can be different and memorized for each video input.
3-1
[H position] + ENTER.
Adjust the Horizontal position with LCD CONTROL + ENTER.
3-2
[V position] + ENTER.
Adjust the Vertical position with LCD CONTROL + ENTER.
3-3
[H size] + ENTER.
Adjust the Horizontal size with LCD CONTROL + ENTER.
3-4
[V size] + ENTER.
Adjust the Vertical size with LCD CONTROL + ENTER.
3-5
[u / over scan] + ENTER.
Select Underscan or Overscan with LCD CONTROL + ENTER.
• [underscan] = Output image is full screen.
• [overscan] = Output image is 10% bigger than in Underscan mode.
3-6
[aspect ratio] + ENTER.
Select an Aspect Ratio with LCD CONTROL + ENTER.
• [4/3] = 4/3 Aspect Ratio.
• [14/9] = 14/9 Aspect Ratio.
• [16/9] = 16/9 Aspect Ratio.
3-7
[brightness] + ENTER.
Adjust the Brightness with LCD CONTROL + ENTER.
3-8
[contrast] + ENTER.
Adjust the Contrast with LCD CONTROL + ENTER.
3-9
[color] + ENTER.
Adjust the Color with LCD CONTROL + ENTER.
3-10
[hue] + ENTER.
Adjust the Tint of the picture (NTSC only) with LCD CONTROL + ENTER.
3-11
[image process] + ENTER.
Select an item with LCD CONTROL + ENTER between:
• NO PROCESSING.
• SHARPNESS 1.
• SHARPNESS 2.
• SHARPNESS 3.
• GAMMA 1.
• GAMMA 2.
• SHARP 1 + GAMMA 1.
• SHARP 2 + GAMMA 1.
3-12
[preset] + ENTER.
• [YES] = Erases all of the Image Settings (#3-1, #3-2, ... #3-11) of the selected input and sets them back to the
factory settings.
• [NO] = Do not erase the Image Settings memorized.
