Chapter 8 : TECHNICAL SPECIFICATIONS SMART FADE™
PAGE 24
Chapter 8 : TECHNICAL SPECIFICATIONS
8-1. VIDEO INPUTS
• RGB/S (4 BNC connectors)
15.625 kHz / 50 Hz .... 15.735 kHz / 60 Hz (625L .....525L).
Levels:
R, G, B = 3 x 0.7 Vp/p.
SYNC. = 0.3 Vp/p or TTL.
Impedance:
RGB = 75 Ohms.
SYNC. = 75 Ohms or Hi-Z.
• COMPONENT (YUV) - R-Y / Y / B-Y (3 BNC connectors).
15.625 kHz / 50 Hz .... 15.735 kHz / 60 Hz (625L .....525L).
Levels:
Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
R-Y = 0.7 Vp/p.
B-Y = 0.7 Vp/p.
Impedance:
Y, R-Y
,
B-Y = 75 Ohms.
• S.VIDEO (Y/C) (4 pin mini DIN connector & 2 BNC connectors).
PAL / SECAM 15.625 kHz / 50 Hz (625L).
NTSC (3.58 MHz / 4.43 MHz ) 15.735 kHz / 60 Hz (525L).
Levels:
Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
C = 0.3 Vp/p (Chroma Burst).
Impedance:
75 Ohms.
• COMPOSITE VIDEO (BNC connector).
PAL / SECAM 15.625 kHz / 50 Hz (625L).
NTSC (3.58MHz / 4.43 MHz) 15.735 kHz / 60 Hz (525L).
Levels:
Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Impedance:
75 Ohms.
8-2. COMPUTER INPUTS (15 PINS HD F connector)
• COMPATIBILITY IN SCALER MODE (NOT SEAMLESS)
Hardware compatibility:
PC, MAC
, WORKSTATION.
Line frequency : from 31.5 kHz to 85 kHz.
Resolution : from VGA (640 x 480) to UXGA (1600 x 1280).
Automatic recognition of Sync. : H & V separate or COMP. Sync.
Levels:
R, G, B = 3 x 0.7Vp/p.
Separate H & V Sync = TTL.
Composite Sync. = TTL & 0.3 V.
Impedance:
R, G, B = 75 Ohms
H = Hi-Z or 75 ohms.
V = 75 ohms.
• COMPATIBILITY IN SEAMLESS SWITCHER MODE
Hardware compatibility:
PC, MAC
, WORKSTATION.
Line frequency : from 31.5 kHz up to 64 kHz
Resolution : from VGA (640 x 480) @ 60 Hz to SXGA (1280 x 1024) @ 60 Hz.
