Casio GRAPH 25+ Pro - Manuel (Page 368)

20051101
4-2
Using a Custom Probe
6. Use the function keys described below to configure the custom probe setup.
• To change the setting of an item, first use the f and c cursor keys to move the
highlighting to the item. Next, use the function keys to select the setting you want.
(1) Slope
Press
1(EDIT) to input the slope for the linear interpolation formula.
(2) Intercept
Press
1(EDIT) to input the intercept for the linear interpolation formula.
(3) Unit Name
Press
1(EDIT) to input up to eight characters for the unit name.
(4) Warm-up
Press
1(EDIT) to input the warm-up time.
7. Press
wand then input a memory number (1 to 99).
• This saves the custom probe setup and returns to the Custom Probe List, which should
now contain the new custom probe setup you configured.
u u u u u To recall the specifications of a Vernier sensor and configure custom
probe settings
1. Perform the first two steps of the procedure under “To configure a custom probe setup” on
page 4-1.
2. Press
5(VRNR).
• This displays a Vernier sensor list.
3. Use the f and c keys to move the highlighting to the Vernier sensor whose setting
you want to use as the basis of the custom probe settings, and then press
w.
• The name and specifications of the Vernier sensor you select will appear on the custom
probe setup screen.
• To complete this procedure, perform steps 4 through 7 under “To configure a custom
probe setup” (page 4-1).
