CENTRIX™ & EVENTIX™ Chapter 6 : EVENTIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
PAGE 53
6-5. LCD FUNCTIONS DESCRIPTION (continued)
6-x-4 [shadow title]: Same function as [title] but a shadow bar appears at the bottom of the image. This function
allows increasing the readability of the text on bright images.
c Select the [duration] of the transition with  + ENTER between :
• [holding]: The text appears after pushing on the TAKE key, and will be removed only by a second
push on the TAKE key.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
d Select the [size] of the shadow bar with  + ENTER.
e
Select the vertical [position] of the shadow bar with  + ENTER.
f Select the [intensity] of the shadow with  + ENTER.
NOTE: The opening & closing animations available with this effect are : CUT, FADE, Horizontal slides.
6-x-5 [hor. wipe]: Allows to switch the pre-selected input onto the MAIN output with a horizontal wipe effect.
c First select a horizontal wipe effect with  + ENTER between:
• [From left]: From left to right.
• [From right]: From right to left.
• [to center]
• [from center]
d Then select the duration of the transition.
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Allows selecting a duration from 0.5 second up to 25 seconds by 0.5 second step.
6-x-6 [vert wipe]: Allows to switch the pre-selected input onto the MAIN output with a vertical wipe effect.
c First select a vertical wipe effect with  + ENTER between:
• [up]
• [down]
• [to center]
• [from center]
d Then select the duration of the transition.
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Allows selecting a duration from 0.5 second up to 25 seconds by 0.5 second step.
6-x-7 [Square wipe]: Allows to switch the pre-selected input onto the MAIN output with a horizontal & vertical
square wipe.
c First select a horizontal wipe effect with  + ENTER between:
• [to center]
• [from center]
d Then select the duration of the transition.
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Allows selecting a duration from 0.5 second up to 25 seconds by 0.5 second step.
