Chapter 5 : USING FRAME STORE AND LOGO INSERTION (continued) CENTRIX™ & EVENTIX™
PAGE 42
5-4. USING FRAME STORE WITH THE REMOTE KEYPAD OR THE EVENTIX ™
This function allows memorizing up to 2 frames (images) in order to display it at any time during the show.
IMPORTANT: The output format used when displaying the frame should be the same that the output format used during
the frame storing.
5-4-1. HOW TO STORE A FRAME
c Select the source of the frame to be stored (with the INPUT SELECTION buttons).
d Select the MAIN or PREVIEW record frame mode (LOGOS/FRAME > record frame > MAIN or
PREVIEW): the device displays a white rectangle corresponding to the frame selection area. If necessary adjust the
position and size of the frame selection area (LOGOS/FRAME > record frame > MAIN or PREVIEW > size or
position).
e Adjust the Luma Key level to get to the desired Luma Keying (LOGOS/FRAME > record frame > MAIN or
PREVIEW > Luma Key).
f Store the frame (LOGOS/FRAME > record frame > MAIN or PREVIEW > store). The memorization starts and
will take about 2 minutes.
NOTE: For motion picture, you can use the FREEZE function, before doing the memorization.
5-4-2. HOW TO ASSIGN A FRAME
g In the assignment menu (LOGOS/FRAME > use logo/frame > assignment), select the displayed input (MAIN or
PREVIEW) that you want to assign the frame, then select frame index select a frame.
NOTE: To remove the frame from an input, select the corresponding input & index and select none.
5-4-3. HOW TO DISPLAY ON or OFF the FRAME
h To display ON the frame, select the input corresponding to the frame with the INPUT SELECTION buttons. The
FRAME appears onto the output, instead of the source connected to this input.
NOTE: If the frame doesn't appear: verify that the display function of the displayed input is not set in the OFF
position (LOGOS/FRAME > use logo/frame > display). In this case, presses ENTER to set it in the ON
position.
i To display OFF the frame, set the display function in OFF position (LOGOS/FRAME > use logo/frame > display
> MAIN or PREVIEW > OFF).
