CENTRIX™ & EVENTIX™ Chapter 3 : OPERATING MODE (continued)
PAGE 29
3-2. OPERATING WITH THE FRONT PANEL OF THE EVENTIX™ (continued)
3-2-1. OPERATING IN MIXER MODE (continued)
• EXAMPLES OF TRANSITION
c PIP effect:
The PIP effect allows to insert an image into another one.
• Press the PIP key, then make all the needed adjustments (duration, size, position...) with  and validate with
ENTER.
• Press the TAKE key to activate the effect (ACTION 1): the PREVIEW image is inserted into the MAIN image.
NOTE:
• You can change the image in the PIP (PREVIEW image) by selecting another input of the PREVIEW
output (ACTION 2): Press the PREVIEW (OUTPUT SELECT) key and select the needed input (the
transition operates with a fading to black).
• You can change the background image (MAIN image) by selecting another input of the MAIN output
(ACTION 3): Press the MAIN (OUTPUT SELECT) key and select the needed input (the transition
operates with a fading to black).
• To remove the PIP effect, press the TAKE key.
See Figure 21: PIP effect. Page 20.
d Title effect (or shadow title):
The TITLE effect allows to display a text onto the MAIN image. For a better readability you also can display a
shadow bar onto your text.
• Create the text to display with the computer connected to the EVENTIX
™ thanks to a drawing software like
PowerPoint® (text in white onto a black background).
• Display on the MAIN output the source to titling, then pre-select the source used for create the text: the image
appears on the PREVIEW output.
• Assign the TITLE effect to one of the USER keys: Press one USER key, select title or shadow title with
and validate with ENTER, then select the duration with  and validate with ENTER.
• Press the TAKE key to activate the effect (ACTION 1): the text is now displayed onto the image of the MAIN
output.
NOTE: You can change the background image (MAIN image) by selecting another input of the MAIN output
(ACTION 2): Press the MAIN output select key and select the needed input (the transition operates with a
fading to black). To remove the TITLE effect, press the TAKE key (ACTION 3).
See Figure 22: Title effect. Page 21.
e Wipe transition:
• Press a USER key, then assign a type of WIPE with the knob  and validate with ENTER (for example:
WIPE > hor wipe > from left), then select the duration with  and validate with ENTER.
• Press the TAKE key to activate the transition: the PREVIEW image appears onto the MAIN display with a wipe
transition.
See Figure Page 22.
