Chapter 6 : EVENTIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued) CENTRIX™ & EVENTIX™
PAGE 48
6-5. LCD FUNCTIONS DESCRIPTION
1 [MODE] + ENTER.
Select a switcher mode between:
• [mixer mode]: Set the device in MIXER mode.
• [matrix mode]: Set the device in MATRIX mode.
2
[INPUT] + ENTER.
2-1 [input type] + ENTER.
c Select an input with  + ENTER.
d Select the input signal type with  + ENTER between:
• [SDTV Composite]
• [SDTV RGBS ana.]
• [SDTV S.VIDEO] • [Computer SOG]
• [SDTV YUV] • [Computer HV/C]
• [SDTV RGBS TTL] • [HDTV]: HDTV input format (720p and 1080i).
• [SDTV RGB SOG] • [SDTV SDI]: optional SDI input.
• [Computer DVI]: Optional DVI input.
e Then for [SDTV Composite], and [SDTV S.VIDEO], select the video standard with  + ENTER between:
• [NTSC / PAL / SECAM]: automatic NTSC, PAL, and SECAM standard detection.
• [NTSC]: NTSC standard only.
• [PAL]: PAL standard only.
• [SECAM]: SECAM standard only. • [B & W 50/60 Hz]: Black and White standard.
2-2 [used input] + ENTER.
Select an input and then select an item with  + ENTER between:
• [used]: A signal is connected to the input.
• [unused]: No signal is connected to the input. The input is unused.
2-3 [H sync load] + ENTER.
Select for each input the load of the H Sync. with  + ENTER.
2-4 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2-5 [synchronized] + ENTER.
This function allows defining the sources which are synchronized together (external genlock). The synchronized
sources can be seamless switched between themselves during an effect (into a PIP for example). This switching
mode is called VIS (Vertical Interval Switching).
2-6 [input status] + ENTER.
Indicates the status of the selected input.
3 [OUTPUT] + ENTER.
3-1 [output format] + ENTER.
Select one of the following output formats with  + ENTER.
• [WVGA:852x480]
• [SXGA+:1400x1050]
• [SVGA:800x600] • [D-ILA - 4/3]
• [XGA:1024x768] • [D-ILA - 16/9]
• [SXGA:1280x1024] • [HDTV 720p]
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format
corresponding to the native resolution of the display device. Thus, the display device will not have to
scale the image and the result will be better.
3-2 [output rate] + ENTER.
Select an output rate between:
• [internal 50Hz]: The output frame is generated at 50 Hz by the device.
• [internal 60Hz]: The output frame is generated at 60 Hz by the device.
• [internal 72Hz]: The output frame is generated at 72 Hz by the device.
• [internal 75Hz]: The output frame is generated at 75 Hz by the device.
• [follow]:
The output frame is synchronized onto one input signal. Select the needed input with
and validate with ENTER.
