18
6. Snap one end of retainer into channel as shown. Push inward
while sliding thumb along full length of retainer.
7. Check door for proper operation. Door should close easily
without slamming and open with its own weight. If necessary,
close door and adjust both door springs by moving spring
ends to different holes in base.
8. Access Panel:
Push up with thumbs on each end of access panel top trim to
unsnap trim. Remove top trim and set it aside.
9. Gently slide color access panel and spacer upward and
remove. Save color access panel and spacer for future use.
10. Insert wood access panel into access panel frame. Slide
panel down into groove along bottom of access panel frame.
It may be necessary to remove the two screws securing top
of access panel to dishwasher frame and tilt access panel
forward to install some wood panels.
11. Line up edges of top trim with sides of access panel frame.
Tilt back of trim down and slide into place. Snap front of trim
down to cover top edge of wood access panel.
Check operation
1. Read the Use and Care Guide that came with your
dishwasher.
2. Check that all parts have been installed and no steps were
skipped.
3. Check that you have all the tools you used.
4. Start dishwasher and allow it to complete the shortest wash
cycle. After the first 2 minutes, unlatch door, wait 5 seconds,
then open door.
5. Check that there is water in the bottom of the dishwasher tub.
Check that dishwasher is working properly.
6. If the dishwasher is not working properly, disconnect power
or unplug dishwasher and see “If dishwasher does not
operate” section.
If dishwasher does not operate
First try the solutions suggested here to possibly avoid the cost
of a service call.
■ Has the circuit breaker tripped or the house fuse blown?
■ Is the door closed tightly and latched?
■ Has the cycle been set correctly to start the dishwasher?
■ Is the water turned on?
If none of these work, call 1-800-253-1301 or in Canada, call
1-800-807-6777.
Spacer
Color panel
Retainer
Channel
Spring
Trim
