EH222 D and Condensing Unit
Remote Low Side Cuber User Manual
October 2014
Page 7
Pre-Installation Details
Note: The ice making section cannot be stacked
vertically.
Accessories such as bin adapters and tubing kits are
required to complete the installation.
Dispenser Adapter Kits:
• Cornelius ABS: KBTABS ED150: KBT40
• Scotsman ID150: KBT40
• Scotsman ID200 or ID250: KBT41
Bin Adapter Kits:
• B530P or B530S: KBT32
• B948S: KBT34
Tubing Kits:
• 20 foot: 3BRTE20-EH
• 35 foot: 3BRTE35-EH
• 50 foot: 3BRTE50-EH
• 75 foot: 3BRTE75-EH
Note: Line set may have quick connects. The
condensing section may have quick connects. See
refrigeration system detailed instructions connection
details.
Items required for installation:
• Ice making head
• Condensing unit (includes interconnecting control
system wire)
• Tubing kit. 20’, 35', 50’ or 75’ triple line set (liquid,
vapor and suction)
• Bin or dispenser adapter
Special Considerations
The ice making section’s footprint is 22” wide by 16.5”
deep. The refrigeration connections can be routed up
or to the back. The drain may be routed out the back
at any position left to right; it may also be routed to
either side.
Water
Pure water does not exist. All water supplies contain
some amounts of impurities, although potable water
is, by definition, fit for human consumption. Because
the contents of the water to an ice machine directly
impact its performance, consideration should be given
to improving the water’s quality.
There are two ways water can contain impurities:
in suspension or in solution. Suspended solids can
be filtered out of the water. In solution or dissolved
solids must be diluted or treated. Water filters are
recommended to remove the suspended solids.
Some filters or filter systems have treatment
chemicals in them for treating the suspended solids.
This ice machine has an adjustment for the amount
of water rinsed or purged. Water use adjustments
are customer convenience adjustments; they are not
factory defects and are not covered by warranty.
