Scotsman EH222 D with ECC Condensing Unit - Manuel (Page 3)

EH222 D and Condensing Unit
Remote Low Side Cuber User Manual
October 2014
Page 3
Configuration
A remote low side cuber system includes two sub
systems: an ice making head and a remote air cooled
condensing unit. This manual covers the EH222 head
and the condensing units that go with it.
The ice making heads are designed for use indoors
in a controlled environment. The remote condensing
units are designed to operate outdoors. Each sub-
system has limits for power, water and temperature.
Operational Limitations:
Minimum Maximum
Air Temp (at head) 50 o F 100 o F.
Air Temp (CU) -20 o F. 120 o F.
Water Temp 40 o F. 100 o F.
Water Pressure 20 psi 80 psi
Water Conductivity 10 microSiemens/cm any
Voltage (at head) 104 126
Voltage (CU) 198 253
CU= Condensing Unit
Do Not operate the machine in conditions beyond
these limitations. Doing so will void the warranty.
Scotsman ice systems are designed and
manufactured with the highest regard for safety and
performance. They meet or exceed common agency
standards.
Scotsman assumes no liability of responsibility of
any kind for products manufactured by Scotsman
that have been altered in any way, including the use
of any part and/or other components not specifically
approved by Scotsman.
Scotsman reserves the right to make design changes
and/or improvements at any time. Specifications and
design are subject to change without notice.
Warranty
Refer to the warranty coverage in effect when the
equipment was sold. Warranty statements are
included with each product.
Systems:
Ice making heads and condensing units have their
own model and serial numbers. They must be
combined to create a remote cuber low side system.
Notes: Voltage Codes are at the end of the model
number. Codes read Voltage/Hertz/Phase. Those
related to these products include:
-1 = 115/60/1
-3 = 208-230/60/3
-32 = 208-230/60/1
System Information
Tubing kits are required to connect the head to the
condensing unit.
Interconnecting 24 volt control wire ships with the
condensing unit.
System Size Condensing Unit (CU) Ice Making Head
Model Electrical (volts/Hz/phase Model Electrical (volts/Hz/phase)
800 ECC0800-32A 208-230/60/1 EH222SL-1D 115/60/1
800 ECC0800-3A 208-230/60/3 same same
1000 ECC1410-32A 208-230/60/1 same same
1000 ECC1410-3A 208-230/60/3 same same
