CONTROL PANEL AND FEATURES
6
CYCLE STATUS LIGHTS
The Cycle Status Lights show the progress of a cycle. At each
stage of the process, you may notice sounds or pauses that
are different from traditional washers.
The Sensing status light comes on as the washer
automatically weighs items, then adjusts the Estimated
Time Remaining, based on the cycle selected.
When the Door Locked LED light illuminates, the door
is locked. The door is locked and unlocked automatically,
depending on the stage of the wash cycle. Press and
hold CANCEL/DRAIN for 3 seconds to unlock the door
manually. It will take approximately 1 minute for the door
to unlock. When the door is unlocked, the Draining/Unlocking
light illuminates.
The Prewash, Wash, Rinse, and Spin lights each come on as
the washer progresses through each cycle.
The Done status light stays on for 1 hour after the cycle is
complete. To power down the washer manually after the wash
cycle is complete, switch knob to the Off position.
CANCEL/DRAIN BUTTON
Press to turn the washer on and off.
Press to stop/cancel a cycle at any time.
ESTIMATED TIME REMAINING
The cycle times vary automatically based on your water
pressure, water temperature, detergent, and clothes load.
The cycle time will be extended if oversudsing occurs or the
load is unbalanced. The oversuds routine removes extra suds
and ensures proper rinsing of your garments. The options you
select will also affect the cycle times that are shown in the
“Cycle Guide.” The Estimated Time Remaining can change
to much longer times under extreme conditions.
OPTIONS
You can customize your wash by adding options to your cycle
selections. Not all options are available with all cycles.
n If an option is available with a selected cycle, the light for
that option will illuminate when selected.
n If an option is unavailable with a selected cycle, there will
be a blinking light. The light for that option will not illuminate
when selected.
1 Delay Start
Use this to begin the wash cycle later.
n Select DELAY START until the desired time (in hours)
shows in the Estimated Time Remaining display.
n Select START. The countdown to the wash cycle will
show in the display window.
Prewash
Prewash is an 18-minute soak phase that is added before
the main wash. During prewash, there is only a small
amount of tumbling.
2nd Rinse
A second rinse can be used to aid in the removal
of detergent or bleach residue from garments. This
option provides an additional rinse with the same water
temperature as in the normal rinse. You may select or
deselect by pressing 2ND RINSE.
Wrinkle Prevent
Use this option to increase the quantity of incoming water
and decrease the spin speed and duration in the rinse
period. The last spin phase will have a lower spin speed
and last a shorter time.
Max Extract
Use this option to increase the final spin period by
1 minute during the final spin.
Low Spin
Each cycle has a preset spin speed. To reduce the final
spin speed, press the LOW SPIN button.
Temp Level
Each cycle has a preset water temperature setting. To
change the water temperature, press the TEMP LEVEL
button until the desired setting is illuminated.
Select a water temperature based on the type of load
you are washing. Use the warmest wash water safe for
fabrics. Follow garment label instructions.
The water temperature for all rinse cycles is cold. Cold
rinses save energy.
START BUTTON
Press and hold to start a cycle, or press once while a cycle
is in process to pause it.
WASH CYCLE KNOB
Turn the Wash Cycle knob to select a cycle for your laundry
load. See “Cycle Guide” for detailed descriptions of cycles
that best suit your load.
