18
Loosen bolts with a 15/32" (12 mm) wrench. Once the bolt is
loose, move it to the center of the hole and completely pull out
the bolt, including the plastic spacer covering the bolt.
3.
Remove transport bolts from
washer
Pull power cord through opening in rear panel.
NOTE: If washer is transported at later date, call your
local service center to avoid suspension and structural
damage, a certified technician must properly set up
washer for relocation.
4.
Remove power cord
ROUTE DRAIN HOSE
6.
Place power cord over top
Remove the yellow shipping strap from the cord. Gently
place power cord over top of washer to allow free access
to back of washer.
IMPORTANT: Do not plug washer in until installation has
been completed.
Gently pull the corrugated drain hose from the shipping
clips.
7.
Remove drain hose from washer
Proper routing of the drain hose protects your floor from damage
due to water leakage. Read and follow these instructions.
Close bolt holes on cabinet back with four transport bolt hole
plugs included with washer parts.
5.
Cover bolt holes with transport
bolt hole plugs
