Level washer, Check levelness of washer, Rock washer to test foot contact – Maytag MHWC7500YW Manuel d'utilisation
Page 20: Connect inlet hoses to washer, Check for leaks, Secure drain hose
20
LEVEL WASHER
Leveling your washer properly reduces excess noise and
vibration.
Remove cardboard from beneath washer.
Place a level on top edges of washer,
checking each side and front. If not level, tip washer and
adjust feet up or down as shown in steps 17 and 18, repeating
as necessary.
15.
Check levelness of washer
place level here
16.
Rock washer to test foot contact
Grip washer from top and rock back and forth, making sure all
four feet are firmly on floor. Repeat, rocking washer from side
to side. If washer rocks, go to step 17 and adjust leveling feet.
If all four feet are in firm contact with floor, go to Step 18.
12.
Connect inlet hoses to washer
Not Level
LEVEL
Not Level
Attach hot water hose to hot water inlet valve. Screw coupling
by hand until it is snug. Use pliers to tighten couplings an
additional two-thirds turn. Repeat with cold water inlet valve.
IMPORTANT: To reduce risk of hose failure, replace the hoses
every 5 years. Record hose installation or replacement dates
for future reference.
n
Periodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.
Slowly turn on water faucets to check for leaks. A small
amount of water may enter washer. It will drain later.
13.
Check for leaks
Secure drain hose to laundry tub leg, drain standpipe, or inlet
hoses for wall standpipe with cable tie.
14.
Secure drain hose
4.5"
(114 mm)
4
1
/
2
"
(114 mm)
4
1
/
2
"
(114 mm)
4.5"
(113 mm)
4
1
/
2
"
(114 mm)
Laundry Tub
Standpipe
Wall
