14
Alternate parts: (Not supplied with washer)
Your installation may require additional parts. To order, please
refer to toll-free numbers on the back page of this manual.
If you have: You will need:
Laundry tub or standpipe Sump pump system (if not already
taller than 55" (1.4 m) available)
Overhead sewer Standard 20 gal. (76 L) 30" (762 mm)
tall drain tub or utility sink, sump
pump and connectors (available from
local plumbing suppliers)
Floor drain system Siphon Break Kit Part Number 285834
Connector Kit (x2) Part Number 285835
Additional Drain Hose Part
Number 8318155
Drain hose too short Extension Drain Hose Part
Number 285863
Connector Kit Part Number 285835
Water faucets beyond 2 longer water fill hoses:
reach of fill hoses 6 ft (1.8 m) Part Number 76314
10 ft (3.0 m) Part Number 350008
Stack Kit:
Are you planning to stack your washer and dryer? To do so you
will need to purchase a Stack Kit.
To order, call the dealer from whom you purchased your washer
or refer to the “Assistance or Service” section. Ask for Part
Number W10178021.
Optional tools:
Parts supplied:
NOTE: All parts supplied for installation are in the washer
basket.
4" min
(102 mm)
Wood block
Adjustable or open end
wrenches 15/32" (12 mm)
and 1/2" (13 mm)
Ruler or measuring tape
Level
Pliers that open to 1 9 ⁄
16
"
(39.5 mm)
Flashlight Bucket
Cable tie
U-shaped hose form
Tools needed:
INSTALLATION REQUIREMENTS
Tools and Parts
Gather required tools and parts before starting installation.
Inlet hoses (2) with
washers
Transport bolt hole
plugs (4)
Options:
Pedestal:
You have the option of purchasing a pedestal for this washer.
You may select an 11.8" (300 mm) pedestal. The pedestal will
add to the total height of the washer.
Pedestal
Height
Approximate
Height with
Washer
Color Model
Number
11.8" (300 mm) 44.7" (1135 mm) White LAB0050PQ
INSTALLATION
INSTRUCTIONS
