English
9
• If MAIN DIRECT is selected as the input source, audio
signals will not be output at the PRE OUT, LINE 2 OUT or
PHONES jacks.
• If LINE 2 is selected, audio signals will not be output at
the LINE 2 OUT jacks.
B PHONO switch
Set this switch to the MM or MC position according to
the type of magnetic cartridge of the turntable
connected to the PHONO input jacks on the rear
panel.
Before you replace the cartridge for the turntable, be sure
to turn off the power to this unit.
C Feet
If the unit is unstable, adjust the height of the feet as
needed by rotating them.
D AUDIO MUTE switch/indicator
Press this switch to reduce the current volume level by
approximately 20 dB. The indicator will light up.
Press again to restore the audio output to the previous
volume level. The indicator will turn off.
E VOLUME knob
Adjusts the volume level. This setting will not affect
the output level at the LINE 2 OUT jacks.
D E C
Note
Note
NOTICE
If you select MAIN DIRECT as the input source for this
unit, the volume level will be fixed. In this case, to adjust
the volume level, use the volume control on the
external amplifier connected to the MAIN IN jacks.
