Residual noise (IHF-A network)
....................................................................... 33 μ Vrms
Channel separation (JEITA, 1 kHz/10 kHz)
PHONO (MC)..................................66/77 dB or higher
PHONO (MM).................................90/77 dB or higher
CD (or similar)/BAL 1/BAL 2 ........74/54 dB or higher
Tone control characteristics
BASS
Boost/cut ................................................. 50 Hz / ±9 dB
Turnover frequency............................................ 350 Hz
TREBLE
Boost/cut ............................................... 20 kHz / ±9 dB
Turnover frequency........................................... 3.5 kHz
Meter accuracy
........................................................................ Class 2.5
Power supply
[Models for U.S.A. and Canada] ....... AC 120 V, 60 Hz
[Model for China] .............................. AC 220 V, 50 Hz
[Model for Korea].............................. AC 220 V, 60 Hz
[Model for Australia]......................... AC 240 V, 50 Hz
[Models for U.K. and Europe]........... AC 230 V, 50 Hz
[Model for Asia] ..............AC 220–240 V, 50 Hz/60 Hz
[Model for Taiwan].............................AC 110 V, 60 Hz
Power consumption
............................................................................ 350 W
Standby power consumption
OFF mode ............................................................ 0.1 W
Standby mode ...................................................... 0.2 W
Maximum power consumption (1 kHz, 4Ω 10% THD)
[Model for Taiwan]............................................. 700 W
Dimensions (W × H × D)
......................................................435 Ч 180 Ч 464 mm
17-1/8" Ч 7-1/8" Ч 18-1/4"
Weight
............................................................................24.7 kg
54.5 lbs
* The contents of this manual apply to the latest
specifications as of the publishing date. To obtain the
latest manual, access the Yamaha website and
download the manual file.
