8
Countertop Requirements
Notes
▯
All measurements given must be precisely followed. If
nonstandard cabinets are used, make sure they are
installed with minimum dimensions shown in image
below.
▯
When installed in combination with a hood, refer to
hood manufacturer’s requirements for installation
30” Models
* Side wall clearance dimensions can be reduced to 6”
(152 mm) if opposing side wall is ≥ 24” (610 mm).
36” Models
* Side wall clearance dimensions can be reduced to 6”
(152 mm) if opposing side wall is ≥ 24” (610 mm).
Mounting Requirements
Use the hold down brackets supplied. See “Install the
Cooktop” section for further details.
Ventilation Requirements
We strongly recommend the installation of ventilation with
the appliance. The appliance must be installed according
to the furnished instructions.
9 CAUTION
The appliance should not be installed with a
ventilation system that blows air downward toward
the burners. This type of ventilation system may
cause ignition and combustion problems with the
gas cooking appliance resulting in personal injury or
unintended operation.
PP PD[Ǝ
JDV
FRQQHFWLRQ
PD[Ǝ PP
JDV
FRQQHFWLRQ
