IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT : SAVE THESE INSTRUCTIONS FOR THE
LOCAL ELECTRICAL INSPECTOR’S USE.
INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE
UNIT FOR THE OWNER.
OWNER: PLEASE RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
WARNING
When properly cared for, your new appliance has been
designed to be safe and reliable. Read all instructions
carefully before use. These precautions will reduce the
risk of burns, electric shock, fire and injury to persons.
When using kitchen appliances, basic safety precautions
must be followed including those in the following pages.
WARNING
Do not repair, replace or remove any part of the
appliance unless specifically recommended in the
manuals. Improper installation, service or maintenance
can cause injury or property damage. Refer to this
manual for guidance. All other servicing must be done by
an authorized service agency.
▯
Install a gas shutoff valve near the appliance. It must
be easily accessible in an emergency.
▯
Leak testing must be conducted by the installer
according to the instructions in this manual.
▯
The appliance and its individual shutoff valve must be
disconnected from the gas supply piping system
during any pressure testing at pressures in excess of
1/2 psi (3.5 kPa).
▯
The appliance must be isolated from the gas supply
piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply
piping system at test pressures equal to or less than
1/2 psi (3.5 kPa).
▯
The minimum supply pressure must be 1” water
column above the manifold pressure printed on the
data plate.
▯
The maximum supply pressure must not exceed 14.0
inches water column (34.9 Millibars).
▯
For Massachusetts installations:
▯
Installation must be performed by a qualified or
licensed contractor, plumber or gas fitter qualified
or licensed by the state, province or region where
this appliance is being installed.
▯
Shut-off valve must be a “T” handle gas cock.
▯
Flexible gas connector must be new and not longer
than 36 inches.
▯
Installer-show the owner where the gas shut-off valve
is located.
Propane Gas Installation
▯
The propane gas tank must be equipped with its own
high pressure regulator. In addition, the regulator
supplied with this unit must also be used.
▯
The appliance is shipped from the factory for use with
natural gas. It must be converted for use with propane.
A qualified technician or installer must do the
conversion.
Equipment and Usage Safety
Requirements
▯
The cooktop must be used in conjunction with a
suitable ventilation system.
▯
Remove all tape and packaging before using the
appliance. Destroy the packaging after unpacking the
appliance. Never allow children to play with packaging
material.
▯
Never modify or alter the construction of the
appliance. For example, do not remove panels, wire
covers or screws.
▯
To eliminate the risk of burns or fire while reaching
over heated surface units, cabinet storage space
located above the surface units should be avoided. If
cabinet storage is to be provided, the risk can be
reduced by installing a hood that projects horizontally
a minimum of 5 inches beyond the bottom of the
cabinet.
▯
Verify that cabinets above the cooktop are a maximum
of 13 inches (330mm) deep.
Appliance Handling Safety
CAUTION
▯
Unit is heavy and requires at least two people
or proper equipment to move.
▯
Hidden surfaces may have sharp edges. Use
caution when reaching behind or under
appliance.
