Plot
Fonction
Distribution des plots X10 pour palpeur d'angles
Distribution des plots X10 pour palpeur d'angles
1
blindage interne
2
prêt
(KT 130)
6
U
P
+5 V
(KT 130)
8
U
P
0 V
(KT 130)
13
signal de commutation
(KT 130)
14
contact
+2.5 V
(KT 120)
15
contact
0 V
(KT 120)
3, 4, 5, 7, 9,
ne pas raccorder
10, 11, 12,
Boîtier
blindage externe
