28
ELECTRONIC CONTROL SETUP INSTRUCTIONS
Code Explanation
7. 00 SPECIAL PRICE START HOUR
NOTE: Uses military time or 24 hr. clock.
7. 00 This is the start hour; 0–23 hours.
•
Select START HOUR by pressing the WHITES AND
COLORS button.
•
Press the PERM. PRESS button once to advance
to next code.
8. 00 SPECIAL PRICE STOP HOUR
NOTE: Uses military time or 24 hr. clock.
8. 00 This is the stop hour; 0–23 hours.
•
Select STOP HOUR by pressing the WHITES AND
COLORS button.
•
Press the PERM. PRESS button once to advance
to next code.
9. 10 SPECIAL PRICE DAY
9. 10 This represents the day of the week and whether special
pricing is selected for that day. A number followed by “0”
indicates no selection that particular day (9.10). A number
followed by an “S” indicates selected for that day (9.1S).
Days of the week (1–7) are selected by pressing the
WHITES AND COLORS button. Press the DELICATES
button once to select special pricing for each day chosen.
When exiting set-up code “9,” the display must show the current
day of week:
DISPLAY DAY OF WEEK CODE ( selected )
10 Day 1 = Sunday 1S
20 Day 2 = Monday 2S
30 Day 3 = Tuesday 3S
40 Day 4 = Wednesday 4S
50 Day 5 = Thursday 5S
60 Day 6 = Friday 6S
70 Day 7 = Saturday 7S
•
Press the PERM. PRESS button once to advance
to next code.
A. 00 VAULT VIEWING OPTION
This option is either NOT SELECTED “OFF” or
SELECTED “ON.”
A. 00 Not Selected “OFF.”
A. SC Selected “ON.”
•
Press the DELICATES button once to change this
selection. When selected, the money and/or cycle
counts will be viewable (if counter option(s) is
selected) when the coin box is removed.
•
Press the PERM. PRESS button once to advance
to next code.
Code Explanation
b. 05 VALUE OF COIN 1
b. 05 This represents the value of coin 1 in number of nickels:
05 = $0.25.
•
By pressing the WHITES AND COLORS button,
there is an option of 1–199 nickels.
•
Press the PERM. PRESS button once to advance
to next code.
C. 20 VALUE OF COIN 2
C. 20 This represents the value of coin 2 in number of nickels:
20 = $1.00.
•
By pressing the WHITES AND COLORS button,
there is an option of 1–199 nickels.
PR MODELS ONLY: For PR models using Enhanced
Debit, this field represents the value of top off in nickels.
PR MODELS: Factory preset for $0.25.
•
Press the PERM. PRESS button once to advance
to next code.
d.00 COIN SLIDE OPTION
This option is either NOT SELECTED “OFF”
or SELECTED “ON.”
d.00 Not Selected “OFF.”
d.CS Selected “ON.”
•
Press the DELICATES button 3 consecutive times
for this selection. When coin slide mode is selected,
set “b.” equal to value of slide in nickels. Set “606”
(REGULAR CYCLE PRICE) and “3.06” (SPECIAL
CYCLE PRICE) to number of slide operations.
NOTE: If the installer sets up “CS” on a coin drop model,
it will not register coins.
•
Press the PERM. PRESS button once to advance
to next code.
E. 00 ADD COINS OPTION
This option is either NOT SELECTED “OFF” or
SELECTED “ON.” This option causes the customer
display to show the number of coins (coin 1) to enter,
rather than the dollars-and-cents amount. The number
in the display changes as the coins are accepted.
E. 00 Not Selected “OFF.”
E. AC Selected “ON.”
•
Press the DELICATES button 3 consecutive times
to change this selection.
PR MODELS ONLY: In enhanced debit mode, this option
is not selectable.
•
Press the PERM. PRESS button once to advance
to next code.
