27
ELECTRONIC CONTROL SETUP INSTRUCTIONS
Code Explanation
1. 00 MONEY COUNTER OPTION
This option is either NOT SELECTED “OFF” or
SELECTED “ON.”
1. 00 Not Selected “OFF.”
1. 0C
Selected “ON.”
•
Press the DELICATES button 3 consecutive times
to select “ON” and 3 consecutive times to remove
(Not Selected “OFF”). Counter resets by going from
“OFF” to “ON.”
1. C0 Selected “ON” and not able to be deselected.
•
To select “ON” and not able to be deselected,
first select “ON,” then within 2 seconds, press
the DELICATES button twice, the WHITES AND
COLORS button once, and exit set-up mode.
•
Press the PERM. PRESS button once to advance
to next code.
2. 00 SPECIAL PRICING OPTIONS
This option is either NOT SELECTED “OFF”
or SELECTED “ON.”
2. 00 Not Selected “OFF,” and next available code will be A.00.
2. SP Selected “ON.”
•
Press the DELICATES button once to change this
selection.
If SPECIAL PRICING OPTION is selected, there is access
to codes “3.XX” through “9.XX.”
•
Press the PERM. PRESS button once to advance
to next code.
If money counter (1.0C or 1.C0) is selected, the following
is true:
3 00 Dollars in HUNDREDS 3 01 = $100.00
4 00 Dollars in ONES 4 68 = $ 68.00
5 00 Number of CENTS 5 75 = $ 00.75
TOTAL = $168.75
OPTIONS 3.XX – 9.XX TO USE IF SPECIAL PRICING
IS SELECTED
Code Explanation
3.06 SPECIAL CYCLE PRICE
3.06 Represents the number of quarters (coin 1) to start the
dryer; may adjust from 0–39. (See VALUE OF COIN 1
b.05.)
Advance from 0–39 by pressing the WHITES AND
COLORS button. Factory default of 6 quarters = $1.50.
PR MODELS ONLY: Factory preset for 0 quarters.
•
Press the PERM. PRESS button once to advance
to next code.
4.05 SPECIAL DRY TIME
4.05 Represents the number of minutes per quarter (coin 1).
•
Factory default of 5 minutes per coin.
Example: 6 quarters x 5 minutes = 30 minutes.
•
By pressing the WHITES AND COLORS button,
the value can be adjusted from 1–99 minutes.
•
Press the PERM. PRESS button once to advance
to next code.
5. 00 TIME-OF-DAY CLOCK, MINUTES
5. 00 This is the TIME-OF-DAY CLOCK, minute setting; select
0–59 minutes by pressing the WHITES AND COLORS
button.
•
Press the PERM. PRESS button once to advance
to next code.
6. 00 TIME-OF-DAY CLOCK, HOURS
NOTE: Uses military time or 24 hr. clock.
6. 00 This is the TIME-OF-DAY CLOCK, hour setting; select
0–23 hours by pressing the WHITES AND COLORS
button.
•
Press the PERM. PRESS button once to advance
to next code.
