23
REVERSING DRYER DOOR SWING (OPTIONAL)
9. Attach door hinges to dryer door so that larger hole is at the
bottom of the hinge and the hinge pin is toward the door front.
10. Remove the 4 screws that attach 2 plugs on the left side.
Attach plugs to right side using the same 4 screws.
11. Insert screws into bottom holes on left side of cabinet. Tighten
screws halfway. Position door so large end of door hinge slot
is over screws. Slide door up so screws are in bottom of slots.
Tighten screws. Insert and tighten top screws in hinges.
12. Close door and check that door strike aligns with door catch.
If needed, slide door catch left or right within slot to adjust
alignment.
You can change your door swing from a right-side opening to
left-side opening, if desired.
Remove the Door Assembly
1. Place a towel or soft cloth on top of work space to avoid
scratching of the surface.
2. Open dryer door. Remove button screws from cabinet side
of hinges. Loosen (do not remove) top screws from cabinet
side of hinges.
3. Lift door until top screws in cabinet are in large part of hinge
slot. Pull forward off screws. Set door (handle side up) on top
of towel. Remove top screws from cabinet.
4. Remove screws attaching hinges to door.
5. Remove screws at top, bottom, and side of door (5 screws).
6. Holding door over towel, grasp sides of outer door and gently
lift to separate it from inner door. Do not use a putty knife to pry
apart. Do not pull on door seal or plastic door catch.
7. Be certain to keep cardboard spacer centered between doors.
Reattach outer door panel to inner door panel so handle is on
the side where hinges were just removed.
8. Reattach screws at top, bottom, and side of door (5 screws).
Door catch
Hinges
Plugs
