26
ELECTRONIC CONTROL SETUP INSTRUCTIONS
Control Set-up Procedures
IMPORTANT: Read all instructions before operating.
The fabric setting buttons along with the digital display are used
to set up the dryer controls. The display can contain 4 numbers
and/or letters and a decimal point. These are used to indicate
the set-up codes and related code values available for use in
programming the appliance.
How to Use the Buttons to Program the Controls
1.
The WHITES AND COLORS button is used to adjust the values
associated with set-up code. Pressing the button will change
the value by increments of one (1). Rapid adjustment is possible
by holding down the button.
2. The PERM. PRESS button will advance through the set-up
codes. Pressing the button will advance to the next available
set-up code. Holding down the PERM. PRESS button will
automatically advance through the set-up codes at a rate faster
than one (1) per second.
3. The DELICATES button is used to select or deselect options.
IMPORTANT: The console must not be opened unless power is
first removed from the dryer. To access connector AA1:
g Unplug dryer or disconnect power.
g Open console, disconnect plug on AA1, close console.
g Plug in dryer or reconnect power.
■
Stacked PD Models: Insert access panel key and turn
counterclockwise.
■ Stacked PR Models: Once the debit card reader is installed
(according to the reader manufacturer’s instructions), the
set-up mode can be entered by inserting a manual set-up
card (supplied by the reader manufacturer) into the card slot.
If manual set-up card is not available, manual set-up mode can be
entered by turning the access panel key.
The dryer is now in the set-up mode.
NOTE: This dryer is preset at the factory and does not require any
programming. However, if you want to change the settings, follow
the “Set-Up Codes” guide below.
■
PD Units are pre-set at the factory for fixed cycle price with
top off.
■
PR units are pre-set for free cycle operation so they can be run
without readers or coins.
Set-Up Codes
■
The PERM. PRESS button will advance you from code to code.
■
The WHITES AND COLORS button will change the code
value.
■
The DELICATES button will select or deselect options.
FOR PR MODELS: The set-up codes are the same as for the PD
models except where noted.
NOTE: On all stacked dryer models, programming selections apply
to both dryers. Stacked dryer selections are accessed by pressing
the LOWER DRYER buttons.
The set-up code is indicated by the one or two left-hand
characters. The set-up code value is indicated by the two or three
right-hand characters.
Code Explanation
606 REGULAR CYCLE PRICE
606 Represents the number of quarters (coin 1) needed
to start the dryer; may adjust from 0–39 (See
VALUE OF COIN 1 b.05). Advance from 0–39 by
pressing the WHITES AND COLORS button. Factory
default of 6 quarters = $1.50.
PR MODELS ONLY: Factory preset for 0 quarters.
•
Press the PERM. PRESS button once to advance
to next code.
705 REGULAR DRY TIME
705 Represents the number of minutes per quarter (coin 1).
Factory default of 5 minutes per coin.
Example: 6 quarters x 5 minutes = 30 minutes.
By pressing the WHITES AND COLORS button, value
adjusts from 1–99 minutes.
•
Press the PERM. PRESS button once to advance
to next code.
800 TYPE OF DRYER PRICING
800 Fixed Cycle with Top Off. For detailed description, see
“General User Information.”
8FC Fixed Cycle. For detailed description, see “General User
Information.”
Use DELICATES button to make this selection.
PR MODELS ONLY: Factory preset for FC.
•
Press the PERM. PRESS button once to advance
to next code.
9 00 CYCLE COUNTER OPTION
This option is either NOT SELECTED “OFF” or
SELECTED “ON.”
9 00 Not Selected “OFF.”
9 0C Selected “ON” and not able to be deselected.
•
Press the DELICATES button 3 consecutive times
to select “ON.” Once selected “ON” it cannot be
deselected.
•
Press the PERM. PRESS button once to advance
to next code.
If cycle counter (9 0C) is selected, the following is true:
1 00 Cycles in HUNDREDS 1 02 = 200
2 00 Cycles in ONES 2 25 = 25
TOTAL CYCLES = 225
This is “VIEW ONLY” and cannot be cleared.
•
Press the PERM. PRESS button once to advance to next code.
