Curtis DRC8335 - Manuel (Page 18)

18
VCR playback
Basic playback
1. Tune the TV to the AV channel connected with the unit.
2. Insert a tape in the tape deck.
3. Press PLAY/PAUSE
(on the unit, under the tape deck) or
PLAY (on the remote control) to start playback.
4. Press STOP/EJECT or STOP to stop playback.
5. Press STOP/EJECT or STOP again to eject the tape.
Advanced playback
t Quick search – Press REV /FWD during playback to
start backward or forward quick search. Press PLAY to
resume normal playback.
t Frame advance – Press PAUSE to pause playback. Press
PAUSE repeatedly to advance frame by frame. Press
PLAY to resume normal playback.
t Slow motion – Press PAUSE and then
REV /FWD to start backward or forward slow
motion playback. Press PLAY to resume normal playback.
t Skipping – Press or during playback (or SKIP +/– on
the unit) to skip to the previous or next recording on the
tape.
t Tracking – Press TRK –/+ repeatedly to remove any
streaks from the picture, if necessary.
Reset counter
Press COUNTER RESET on the remote control to set the
counter back to 0.
Go to zero
Press GO TO ZERO on the remote control to fast forward or
rewind the tape to the point that you selected as the 0 point
(above).
Audio channel
Press AUDIO during playback to change the audio to one of
the following: stereo, left channel only, right channel only or
mono. Channels available depend on the recorded program.
Repeat
Press PLAYMODE to select between repeat on and off.
When repeat on is selected, the tape will be rewinded and
played repeatedly when it comes to the end. When repeat
mode is activated, all other playback operations will be
disabled except the stop function.
Info banner
Press INFO to display or hide the info banner for checking
the counter, playback time, audio setting and repeat mode.
VCR control keys
VCR selection key
Playback control keys
Tracking keys
Audio channel key
Counter reset key
Repeat key
Info banner key
Make sure the VCR is selected with the VCR
indicator turned ON when using the remote control
to perform the below operations. If the indicator is
off, press VCR on the remote control to activate the VCR.
VCR
indicator
Press this
button
Go to zero key
DRC8335_EN(verB) 7/23/07 3:36 PM Page 20
