Radson 4 Zones RF Clock - Manuel (Page 26)

26
To enter the value shown on the thermometer, use
the (-) or (+) keys to enter the real value. Then, press
(Ok) to confirm.
The message “Yes” should be displayed; the value
will be stored in the internal memory.
If you need to erase a calibration press on the
escape key (
).
The old value will be erased and the message “no”
will be displayed.
06
In.TY
Type of free contact use with the external input.
No: The option will be activated when the contact is
closed
NC: The option will be activated when the contact is
open.
08 Clr ALL: Reset to Factory setting
Press and maintain (Ok) key during 10s to reset Set
points temperatures and user parameters in this
menu to factory default settings. User programs will
also be resetted.
* Pay attention:
Ensure you that you have all necessary elements to
re-setup your installation before to use this function.
09 Software version
VErS ___
10 End: Exit the parameter’s menu
Press (OK) key to exit installation parameter menu
and return to normal operation.
