Now you can select a parameter which must be adjusted
with the navigation keys
(◄-) or (►+), once the parameter
chosen, toggle the value with the (OK) key, modify it with
(◄-) or (►+) and confirm your adjustment with (OK).
To leave the parameter menu, choose the parameter
« End » and press (OK).
N° Default value & other possibilities
00 init: Radio configuration
Sends the radio link signal in order to assign this RF
Clock with all RF receiver of the installation.
You also need to set simultaneously the receiver in
radio configuration mode. (See chapter RF
installation)
01 Lang: Choose the language of the parameter list.
Engl: English language
Fran: French language
02 dEG: Unit of the temperatures displayed
°
C Celsius
° F Fahrenheit
03 __:__ Selection of the Time clock unit
24H (24:00)
12H (12:00 AM /PM)
04 dst: Daylight Summer time change Summer<-
>Winter
YES: automatic change according to date.
no: no daylight summer time automatic change.
05 AirC: Calibration of the internal probe
The calibration must be done after 1 hour without
manipulation of the clock in accordance with the
following description:
Put a thermometer in the room at 1.5M distance from
the floor (like the clock) and check the real
temperature in the room after 1 hour.
When you enter on the calibration parameter “no” is
displayed on the right to indicate no calibration has
made.
