Radson 4 Zones RF Clock - Manuel (Page 14)

14
Checking rules for Control Conductor Receiver
- First of all, from the main screen press on the menu key
(
i)
and choose the Comfort menu with
(◄-) and (►+).
- Now, put all your radiators in AUTO mode and check the
LED of your control conductor receiver (green fixed LED to
indicate Comfort)
- Then on the clock, from the main screen press on the
menu key (
i)
and choose the reduced menu with (◄-)
and
(►+).
- Now go to the rooms (zones) which must be controlled by
the clock and check all control conductor receivers to be
sure that the new working mode has received (Reduced
mode, green LED blinking).
Now your installation is checked and ready to works.
To make the installation easier it will be better to have the
clock near to the receiver during the configuration mode.
(A minimal distance of > 50cm must be respected to avoid
bad RF reception)
2.4
Starting
The clock is now ready to works.
The default working mode will be automatic with a
standard built-
in program “P1” for all the zones.
Monday to Friday
20°C
18°C
07:00 09:00 17:00 23:00
