Radson 4 Zones RF Clock - Manuel (Page 18)

18
If you chose a user program U1 to U4,
As above you can choose the program, see it,
but you can also customise it in the Program Mode .
3.6 Program Mode
Press (
i) and (◄-) or (►+) to reach the Program mode.
Use this mode to customise the User programs U1 to U4.
Default setting:
U1, U2, U3, U4 = Comfort all the week
Symbols and explanation for program creation:
First step of the day ( Comfort temp.)
The wakeup hour need to be adjusted.
Middle step of the day ( Reduced temp.)
The leaving hour need to be adjusted
Middle step of the day ( Comfort temp.)
The comeback hour will need to be adjusted
Last step of the day ( Reduced temp.)
The sleeping hour need to be adjusted
- The program step is 30 minutes
- Each time a value or icon blinks you are invited to make a
choice with
(◄-) or (►+) keys,
once the choice is made press the (OK) key to jump to the
following step.
- The program creation will always start with the day 1
(Monday).
Once you have pressed the (OK) key, the following display
will appear:
