Names and functions of parts (remote control)
a
b
c
d
e
f
g
h
i
j
k
l
m
n
o
When both the main unit and the remote control have
buttons with the same functions, the instructions in this
manual refer to only one set of buttons, but the other
set of buttons can be used in the same way.
a
PAIRING button
Use this when pairing with other Bluetooth devices
and when ending Bluetooth connections (pages 25
and 26).
b
Standby/on (¤) button
c
SLEEP button
Use this button to set the sleep timer (page 32).
d
TIMER button
Use to turn the wakeup timer on and off (page 30).
e
TUNE/MULTI JOG buttons
When setting the clock and the wakeup timer, use to
set the time (pages 15 and 30).
When listening to an MP3/WMA file, use to select the
folder number (page 20).
f
Skip/search (.m/,/) buttons
When listening to the radio, use to select preset radio
stations (page 29).
When listening to a CD, use to skip to the previous or
next track/file. Press and hold during CD or MP3/WMA
file playback to search forward/backward (page 19).
g
Stop (8) button
Press to stop playback.
h
Play/pause (y/9) button
Press when stopped or paused to start playback.
Use this button to pause playback during playback
(page 19).
i
TONE button
Use to adjust the bass and treble (page 16).
j
MUTE button
Use this button to mute the sound temporarily (page
17).
k
Function button
Each time you press this button, the source will
change as shown below.
CD Bluetooth FM AM
o Press when the unit is in standby mode to turn it
on.
l
DISPLAY/DIMMER button
Each time this button is pressed, the display changes
(page 17).
Press and hold to adjust the display brightness (page
17).
m
MEMORY/CLOCK ADJ button
Use for CD programmed playback (page 20).
When listening to the radio, use when setting radio
station presets (page 28).
Use to adjust the clock (page 15).
12
